PML1000kg Permanent Strong Magnetic Lifters Made in China
- 500000 Set / Sets per Month
- Qingdao Shanghai Ningbo
- T/T Credit Card
- Steel Scrap Lifting Magnet For Excavator Crane Electromagnet In Scrapyard
- Lifting Electromagnet for Handling Steel Billets and Rounds of strong Magnetise Penetration MW12 Series
- MW5 High-temperature Series Lifting Electromagnet for Handling Scraps
- Lifting Electromagnet for Handling Scraps MW5 Standard Series
- Automatically/Manually/Lever/Crown Bar Type Permanent Lifter with Large Lifting Capacity YC/YX Series
- Lifting Electromagnet for Handling Steel Plates MW84/MW04 Series
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | bafang |
Model Number: | PML | Dimension(L*W*H): | 30*14.8*19cm | Certification: | ISO9001 |
Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
PML1000kg Permanent Strong Magnetic Lifters Made in China
The permanent magnetic lifter can be used in a variety of industries for the transportation and lifting of steel, engine parts.
Main feature:
Newland Magnetics' Lift magnets are designed and made for powerful lifting and safe use. These compact lift magnets are used for holding, carrying and releasing round or flat ferrous parts without any electrical power supply.
1.Safe and easy operation:
The handle controls an inner magnetic system for safe and easy operation. When the handle is in the "off" position the Lift magnet has almost no magnetic pull. After you press a button on the top of the handle and turn it to the "on" position, the lift magnet will have attracting pull to a steel load. For more safety, the handle has been locked at this position by a "Lock Pin" and the lift magnet will keep full magnetic pull until you manually slide back the Lock Pin and turn the handle back to the "off" position.
2.Compact yet powerful:
Thanks to Neodymium magnet and special magnetic design, the Lift Magnets have small size and light weight compared to the powerful lift capacity.
3.Constant and stable magnetic power:
The Lift Magnets have high resistance to demagnetization and is shielded from outside magnetic interference with mild steel case. The lifting value will keep constant and stable.
Main Parameter:
Model | Capacity (kg) | Max breakaway force(kg) | Cylindrical lifting strength(kg) | W | L | H | I | Operation temperature(℃) | Net weight (kg) |
PML-100 | 100 | 350 | 50 | 62 | 92 | 67 | 126 | <80 | 3 |
PML-300 | 300 | 1050 | 150 | 92 | 162 | 91 | 155 | <80 | 10 |
PML-600 | 600 | 2100 | 300 | 122 | 232 | 117 | 196 | <80 | 20 |
PML-1000 | 1000 | 3500 | 500 | 176 | 258 | 163 | 285 | <80 | 40 |
PML-2000 | 2000 | 6000 | 1000 | 234 | 378 | 212 | 426 | <80 | 60 |
PML-3000 | 3000 | 10500 | 1500 | 286 | 458 | 261 | 521 | <80 | 90 |
PML-6000 | 6000 | 21000 | 3000 | 296 | 720 | 266 | 700 | <80 | 398 |
