Automated Guided Vechile/Two-Way Lurking AGV
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer, Trading Company
Year Established:
2007
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AGV-Automated Guided VehilcleNegotiableMOQ: 1 -
SMT Specialized AGV-automated Guided VehicleNegotiableMOQ: 1 Set
-
Trolley Type AGV-automated Guided VehicleNegotiableMOQ: 1 Set
-
Two-Way Lurking AGV-automated Guided Vehicle, Patent PendingNegotiableMOQ: 1
-
Lurking Pull Type AGV-automated Guided Vehicle, Patent PendingNegotiableMOQ: 1
Specifications
Two-Way Lurking AGVTwo-Way Lurking AGV
Two-Way Lurking AGV is applied in limited space. Single channel driving, the AGV lurks under the tooling car, uses the motor-driven lift rod hanger to hook and drag the trolley. It reads the landmark instruct through magnetic strip navigation. It separates with the trolley automatically after reaching the designated spot. Then it hides under the empty trolley and drags it away, doing alternating motion.
AGV Driving Route Map Case
Technical parameters
| Overall Dimension | L2250*W410*H280(mm) |
| Moving Way | Magnetic stripe navigation |
| Moving Directions | Going ahead, back ,turning to the left and the right, bifurcating |
| Means of Communication | Wireless Local Area Network |
| Driving Mode | Differential driving |
| Driving Power | DC24V ,DC48V |
| Carrying Capacity | 300Kg ,500Kg,750kg,1000kg (or custom made) |
| Model | Two-Way Lurking AGV |
| Carrying Capacity | 30-45m/minute(or custom made) |
| Turning Radius | The minimum could be 800mm(the magnetic stripe path lays the radius) |
| Navigation Accuracy | ±10mm |
| Manner of Working | 24hours |
| Climbing Capacity | 3-5° |
| Stop Precision | ±10mm |
| Charge Methods | Manual Charging /Automatic Charging |
| Safety Induction Scope | ≤3m,adjustable,the urgent braking length is less than 20mm |
| Alarm Form | Acousto-optic Alarm |
| Storage Battery | Maintenance free charging, continuous discharge times are more than 300. |
| Safety Protection | The front obstacle detects the sensor + machinery anticollision mechanism double protection |
| Designed Life | More than 10 years |
AGV Frame diagram
Application schematic diagram
