Product Details
Condition: | New | Place of Origin: | Hunan, China | Brand Name: | kingkar |
Model Number: | kingkar10000 | Voltage: | 3 phase 380 V | Rated Power: | 30KVA |
Dimension(L*W*H): | 1350*880*1880 | Weight: | 620kg | Certification: | CE and Iso, CE.ISO |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Technical parameter:
Model | Kingkar10000 |
Input power | 3 phase 380 V (50-60) HZ±10% |
Rated capacity(KVA) | 15 |
Working current(A) | 300 |
Max.Work pressure(Mpa) | 0.2 |
Max.Relative humidity(%) | 90 |
Rated gas production(L/H) | 10000±10% |
Water consumption(L/H) | 5.4 |
Maximum cutting thickness(mm) | 400 |
Effective perforation thickness(mm) | 110 |
Cooling way | Air cooling |
Insulation class | F |
Power supply protection grade | IP21S |
Flame temperature(°C) | 800-3200 adjustable |
Working medium | Filtered water or deionized water |
Way to work | continuous |
Environment temperature(°C) | 0-40 |
Appearance size(L×W×H)mm | 1350×880×1880 |
What is HHO Flame Cutting Machine:
Oxyhydrogen Generator/Metal Cutting Machine consumes water and electricity, electrolyze water into H2 and O2, we can use H2 and O2 as source of flame replacing acetylene or natural gas or other fuel.
Oxyhydrogen Generator/Metal Cutting Machine is used for welding, cutting, polishing, brazing, glass processing and jewelry processing. Also can burst with other fuel together for heating.
Multi-functions application:
1.Carbon Steel Cutting of machine building industry,shipyard,steel structure processing plant.
2.Continuous casting slab cutting of Steel Plant.
3.Cooperate with manual cutting torch, semiautomatic cutting machine, shape cutting machine, CNC cutting machine to instead of traditional fuel gas.
Features of Kingkar HHO Flame Cutting machine compared with acetylene propane etc. gas fuel:
1.Oxyhydrogen gas flame is concentrated. Preheating time is short in the same energy condition.This provides higher heat transfer rate, higher piercing speed and faster cutting.
The shorter piercing time and increased cutting speed provides a significant cost saving when compared with LPG fueled cutting.
2.The heat affected zone of oxy-hydrogen flame is small.
3.Oxyhydrogen Cutting is barely have hang slag, cutting section have a good vertical.
4.Oxyhydrogen cutting has no pollution, no black gas, it is environment friendly and not harm for people's body.
Furthermore, Hydrogen gas is avirulent insipidity, but acetylene, propane and other industrial gas include sulphide,lead compounds and etc.
harmful substances, they will cause respiratory disease if workers inhaled.
5.Lower heat stress
Steel plate when heated for the same time by both conventional and Hydrogen fueled flames shows the following heat distribution in the plate.
The high combustion speed of the Hydrogen flame reduces the flame area and concentrates the thermal energy.
This allows the high pressure oxygen passage to heat only the immediate area being cut, preventing excessive heat transfer to the surrounding area.
This reduces cooling time and distortion caused by excessive heat stress.
6.Energy saving effect is prominent.
(1.HHO Flame Cutting Machine uses water and electricity, electrolyze water to H2 and O2, no need gas cylinder, this way saves the cost of gas cyliner's rent,handling,storage.
(2.Oxyhydrogen cutting produces some low pressure oxygen by itself, preheating oxygen can be saved, there just need some hyperbaric oxygen.
Factory Exhibition:
CERTIFICAION :
