Professional Automotive Inspection Camera Borescope Video Flexible Endoscopes With High Quality

Yunhe Qiaoda Technology Co., Ltd. Gold Verified Supplier

5Yrs

US$ 1,300 - 2,100 MOQ: 1 Unit

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Model Number:

RS-28300~RS-283000B

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name NG

Model Number RS-28300~RS-283000B

Power Electronic

Usage Other, pipe inspection

Professional automotive inspection camera borescope video flexible endoscopes with high quality

Product Description

3m,5m,10m, 20m , 25m and 30m can be available for 25mm pipeline video borescope . Cables are changeable

Plumbing Camera Specification:

Item No: RS-28300~283000

Description:

OD:28mm/ Length: 300cm ~3000cmGlass Fiber Cable,PE Coating

Features:

• Gamma correction

• Defect correction

• Edge enhancement

• Automatic Exposure Control(AEC)

• Automatic Gain Control(AGC)

• Automatic White Balance(AWB)

• 50Hz,60Hz flicker automatic cancellation

• High image quality and high low light performance

• Use LEDs as auxiliary light source

Camera 28mm diameter Video Probes
Image Sensor	1/4inch.Color CMOS Image Sensor
Pixel Count (Dynamic/Static)	640 (H) × 480 (V)
Exposure	Automatic
Auto White Balance	Automatic
Video Format	PAL
Interface	Composite Video
Gain Control	Automatically
DC Voltage In	DC 3.7 V ± 5%
Power Consumption	430mW(LED off), 650mW(LED max)
Lens Fno	2.6
Housing	Copper with nickel coating
Field of View(FOV)	73degree
Depth of Field (DOF)	5cm ~ 60cm

Operating Environment
Tip Operating Temperature	-20 to 70 C (-4 to 158F)
Storage Temperature	-20 to 70 C (-4 to 158F)
Relative Humidity	95% max
Waterproof	IP57(Insertion tube and tip)
Hazardous Environments	Not rated for use in hazardous environments
