Humidify System Fog Nozzle,anti-drip Mist Nozzle,metal Fog Nozzle
US$ 0.9 - 1.5
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
QD fog nozzle
Model Number:
QD-NZ005 FOG NOZZLE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Pressure Water Misting Nozzles Pipe Joint Meatal ConnectorUS$ 0.7 - 1.5MOQ: 50 Pieces -
High Quality 0.2L Low Cost Indoor Mist Cooling SystemUS$ 150 - 300MOQ: 1 Unit
-
High Pressure 3L Outdoor Water Mist Cooling Fog SystemUS$ 400 - 800MOQ: 1 Unit
-
7L 1800W 60bar Dedusting and Deodorization Misting System Fog Machine for FactoriesUS$ 500 - 1,000MOQ: 1 Unit
-
0.2L 24V 40bar High Presure Mini Mosquito Fog Machine for Home UseUS$ 150 - 300MOQ: 1 Unit
Place of Origin
Zhejiang, China
Brand Name
QD fog nozzle
Model Number
QD-NZ005 FOG NOZZLE
Sprayer Type
Pump
Material
Metal
Metal Type
Stainless Steel
Usage
Garden
Fog nozzle
Humidify system fog nozzle,anti-drip mist nozzle,metal fog nozzle
Product Description
- Metal fog spray nozzle consists of brass/SS body with internal SS/ceramic core and stainless steel guide vane (with a leak-proof device).
- The liquid flows at high velocity under the water pressure of 70kg to 120kg, forming centrifugal swirl and spraying very fine hollow droplet.
- It is equipped with TEFLON strainer and the fog droplet sizes are about 30um.
- Widely used in workshop moistening salt spray test,man-made fog and other moistening locations.
- The nozzle saves 10 times or above cost than that of moistening by air.
- Thread size: 10/24,12/24 UNC,1/8',3/16"
- Spray pattern:full cone
- Orifice: stainless steel,ceramics.
- Thread screw:BSPT or NPT.
| Performance Data | |||
| Fog Nozzle | Orifice Diameter | Operation Pressure | Flow Rate |
| FD1 | 0.15mm | 20-70kg/cm | 20-46ml/min |
| FD2 | 0.20mm | 49-89ml/min | |
| FD3 | 0.30mm | 80-145ml/min | |
| FD4 | 0.40mm | 95-178ml/min | |
| FD5 | 0.50mm |
130-243ml/min |
|
Commen Application
1. Wetting & Rust removal
2.Humidify for space
3.Chemical treatment
4.Chemical agent spraying
5.Liquid coating
6.Humidify for tabacco leaf
7.Pill coating
8.Evaporative cooling for flue gas
9.Disinfection & sterilization
10.Parts cooling
11.Fruit wax injection
12.Ceramic tile glazing
13.Humidify for factory
14.Salt fog test
15.Artificial fog
16.Humidify for other place
