Rotary tiller, Diesel rotary tiller, Mini diesel rotary tiller, tiller, diesel tiller, mini tiller, diesel mini rotary tiller
Cultivator Accessories/ Tools:
walking wheel:400-8mm type ,500-12mm type, 600-12mm type
Blades and ditch
Strong wooden case
| Model | YL-1WG4.0C | ||
| Tiller | Transmission | Gear driving | |
| Clutch | Wet friction plate | ||
| Gear Shifting | -1,0,1,2, | ||
| Productivity(m2/h) | ≥400 | ||
| Tilling Depth(mm) | 120~300 | ||
| Tilling Width(mm) | 950~1050 | ||
| Tyre size(mm) | 400-8 | ||
| Net Weight(kg) | 105 | ||
| Dimension(mm) | 920x820x580 | ||
| Engine | Engine Model | 178F | |
| Engine Type | diesel direct injection,Single Cylinder,air cooled,4-stroke,vertical | ||
| Horse Power/Rotary Speed(rpm) | 7HP/3600 | ||
| Power | 3.6kw | ||
| Max. power | 4kw/3600 | ||
| Bore x stroke(mm) | 78x62 | ||
| Compression Ratio | 1 9:1 | ||
| Spark plug gap(mm) | 0.7 to 0.8 | ||
| Fuel consumption(g/kw.h) | 280 | ||
| Fuel Tank Capacity(L) | 3.5 | ||
| Displacement(ML) | 296 | ||
| Starting | Recoil start | ||
| Tool | Type(mm) | 40-8mm | |
| Tilling Depth(mm) | 200-300 | ||
| Tilling Scope(mm) | 950-1200 | ||
| Others | Certificate | CE ISO9001 | |
| Package size(mm) | 920x820x580 | ||
| 40HQ loading | 156 sets | ||
As a rotary tiller, it can do rotary tillage and weed work both in paddy and dry fields with higher efficiency and better performance.
Application scope :dry fields,paddy and dry fields . And it can also sow and fertilize and plough when conncted with corollary equipment like sower and fertilizer ,reversible plough ,ect
Characters of the Machine:
1. The machine is compact, light with high working stability. It is easy to operate, and women can also operate it with facility.
2. It is flexible. The handles of the machine are adjustable according to the height of the operator and the needs of the terrain so that it can improve work quality and make the operator more comfortable.
As a good China tiller supplier, we have below advantage:
1. Good quality and competitive price
2. OEM service is available
3. SAMPLE is available
4. Fast and on time delivery
5. 6 month warranty
6. With Strong technical support, professional service, we aim for long term cooperation with you.
