Robin Water Pump. Robin Pump. Gasoline Water Pump by Robin Engine . Japan Type Water Pump

Name: Robin Water Pump. Robin Pump. Gasoline Water Pump by Robin Engine . Japan Type Water Pump
Brand: ROBIN
SKU: 140881168

Negotiable MOQ: 50 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

ROBIN

Model Number:

PTG310

Zhejiang Yongli Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name ROBIN

Model Number PTG310

Theory Centrifugal Pump

Structure Gear Pump

Usage Water

Power Other, GASOLINE ENGINE

Standard or Nonstandard Standard

Fuel Gasoline

Pressure High Pressure

Application Other

Specifications

Robin clear water pump
1. Vibration-proof design high performance
2. Power by Robin engine
3. Self-priming centrifugal pump

JAPAN Type Robin water pump ( Gasoline and kerosene)

3"water pump by robin engine
Engine Model: EY20
Service for long time
6 months warranty

Robin water pump

Model	PTG-207	PTG-307
Type	Self-priming centrifugal pump
suction*delivery(mm)(inch)	5050 22	8080 33
Total heah(m)	46	32
Suction head(m)	8	8
Max delivery volume(m³/h)	36	60
mechanical seal	ceramiccaon
Engine model	EY20-A	EY20-A
Fule tank capacity(L)	3.8	3.8
Starting system	Recoil starter
Packing size(LWH)mm	500380445	500380445
20FT unit	330	330
Net weight(KG)	26	28

Kerosene water pump
Model	PTK-210	PTK-310
Type	Self-priming centrifugal pump
suction*delivery(mm)(inch)	5050 22	8080 33
Total heah(m)	46	32
Suction head(m)	7	7
Max delivery volume(m³/h)	36	60
mechanical seal	Carbon ceramic FSH on
Engine model	EY20-AK
Type	Air-cooled,4-cycle,single cylinder,side valve
Bore*stroke(mm)	67*52
Displacement(cm³)	183
Rated output KW(HP)/rpm	2.3(3.1)/3600
Max output KW(HP)/rpm	3.2(4.3)/4000
Direction of rotation	Counterclockwise,facing PTO shanft
Fuel	Kerosene(automobile gasoline when starting>90#)
Fuel tank capacity(L)	Gasoline 0.17 Kerosene 3.4
Lubrucaoting oil capacity (L)	0.6
Spark Plug	E6TC
Starting system	Recoil starter
Packing size(LWH)mm	500380445
20FT unit	330	330
Net weight(KG)	26	28
