Specifications
High pressure Water Pump, gasoline water pump65meter, high pressure water pump
Agricultural irrigation water pump
pumps
CE
High pressure Water Pump, gasoline water pump :
Water pump price, Usage:
1. Agriculture Irrigation water pump, water transportation pump
2. Urban city underground water draining,centrifugal water pump
3. Aquaculture draining and input water, irrigation water pump
4. Seawater pump, pumping machine
5. Fire fighter water pump, fire-extinguishing
Water pump parts, Material:
Pump body, outlet, inlet flange: Aluminum Alloy (ADC12)
Impeller and Diffuser: Cast Iron, water pump material
Curved Shaft: Forged Steel or Cast Iron
Camshaft: Cast Iron or nylon (Plastic)
| Mode | YL-GHP50, High pressure Water Pump | |||||
| Suction Port Diameter | 2" | |||||
| Discharge Port Diameter | 2" | |||||
| Suction Head | 7m | |||||
| Total Head | 55m | |||||
| Flow Rate | 500L/min | |||||
| Start Mode | Recoil/Electric Start | |||||
| Fuel Tank Capacity | 3.6L | |||||
| Net Weight | 24Kg | |||||
| Dimensions | 520*385*440mm | |||||
| Engine Mode | YL168F-1/P | |||||
| Type | Single-cylinder,Air-cooled,4-Stroke,OHV | |||||
| Engine Speed | 3600rpm | |||||
| Rated Output | 3.5KW | |||||
| Bore*Stroke | 68*54mm | |||||
| Displacement | 196cc | |||||
| Lube-oil Capacity | 0.6L | |||||
High pressure Water Pump:
Water Pump set, Layout picture:
| Model | YL168F-1/P | |||||
| Type | Single-cylinder,Air-cooled,4-Stroke,OHV | |||||
| Crankshaft Direction | Clockwise from flywheel end | |||||
| Cooling Type | Force air-cooled | |||||
| Lubrication type | Splash | |||||
| Ignition Syetem | TCI | |||||
| Spark plug clearance | 0.7-0.8mm | |||||
| Fuel | ≥90# Unleaded Gasoline | |||||
| Start Mode | Recoil/Electric Start | |||||
| Engine Speed | 3600rpm | |||||
| Rated Output | 3.8KW | |||||
| Consumption rate of fuel | ≤395g/Kw.h | |||||
| Consumption rate of machine oil | ≤6.8g/Kw.h | |||||
| Bore*Stroke | 68*54mm | |||||
| Compression ration | 8.5:1 | |||||
| Displacement | 196cc | |||||
| Fuel Tank Capacity | 3.6L | |||||
| Lube-oil Capacity | 0.6L | |||||
| Net Weight | 15Kg | |||||
| Dimensions | 400*350*385mm | |||||
Why us?
1. We are factory, can provide product with competitive price and great quality
2. We save you time. U never need to find someone else in rush space when your product is in need. You can keep our offer and tell me your demands whenever you like
3. We save you money. Beside product, our ship agent provide very good ship freight and service
4. After sale service support. We guarentee our product quality, and provide problem accessory 1 year for free. Thought the problem is a seldom case.
5. Customerized design and service. We support your sale and offer your needs as tailored
6. Product range, we have five ranges of related produce, including Tiller, Water pump,Generator,Power sprayer and Engines. U never worry to gather different model for same container. We can provide satisfying product instead.
7. 10pcs above can be sent as trial order for sample test. 7 days sample delivery time
Water pump Package: 1 set in a carton box with plastic sponge on top
Water pump, CE Certificate:
