Water Pump ( Cast Iron Pump) With Honda Engine

Zhejiang Yongli Machinery Co., Ltd.
Water Pump ( Cast Iron Pump) With Honda Engine thumbnail-1
Water Pump ( Cast Iron Pump) With Honda Engine photo-1
Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YOLEE
Model Number:
YL-GWP50B
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo /shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YOLEE
Model Number YL-GWP50B
Theory Centrifugal Pump
Structure Piston Pump
Usage Water
Power Other, 4KW
Standard or Nonstandard Standard
Fuel Gasoline
Pressure High Pressure
Application Fire

Specifications

Gasoline Water Pumps:
1. half a year warranty
2.Easy maintenance
3.Used for irrigation and horticulture
4.Fuel Tank:3.6L







Introduction:

* Powered by air cooled 4-stroke honda engine
* Iron pump body design
* High quality and mechanical sealed equipment
* Compact structure ,light weight,easy operation
* Easy maintenance.





Honda Engine
1) Type: 1-cylinder, 4-stroke, air-cooled gasoline engine
2) Work capacity: 215cm³
3) Max. Output: 7horsepower/3600rpm
4) Ignition system: Non-contact transistor
5) Starting system: Recoil/Electric
6) Fuel tank capacity: 3.6L
7) Continuous operating time: 5hours
8) Engine oil system capacity: 0.6L

Honda engine advantage:

1.iron camshaft

2. With oil alert

3. broker cylinder crankshaft



Water Pump:
1) Diameter of outlet: 2inch
2) Max. Delivery lift:40

2)flow rate: 500L/min

Size and weight:
1) Over dimension(L*W*H): 535*400*420mm
2) Dry weight:28kg



ModelYL-GWP50B YL-GWP65B

Suction port diameter(2") (2.5")
Discharge port diamter(2") (2")
Total head40m 60m
flow rate500L/min 600L/min
Fuel tank capacity3.6L 3.6L
Net weight26KG 24KG
Dimensions535*400*420 535*400*420
Engine modelYL170F YL170F
TypeSingle-cylinder,4-stroke,air-cooled,swirl chamber
Engine speed3000rpm
Engine outpurt4.2KW
Bore*stroke70*54mm
Displacement208cc
Lube-oil capacity0.6L









Water pump ( cast iron pump) with honda engineWater pump ( cast iron pump) with honda engineWater pump ( cast iron pump) with honda engineWater pump ( cast iron pump) with honda engine
