Specifications
Three phase Gasoline Generator with honda engineCompetitive price gasoline generators
Good quality gasoline generators
Three Phase Gasoline Generator with honda engine
Product Description
Model: MR-GGT3003
Rated Voltage: 220V /380V
Rated frequency: 50Hz
PHASE: 3
Rated output power: 2, 000W
Maximum output power: 2, 200W
DC output: 12V 8.3A
Engine model: EM168F
Engine type: 4-stroke, 1- cylinder OHV Air-cooled gasoline engine
Bore x stroke: 68 x 45mm
Displacement: 163CC
Maximum power output: 5.5HP/3600rpm
Ignition system: T. C. I.
Starting system: Recoil starter /Electric starter and battery
Fuel tank capacity: 15L
Dimensions: 610 x 450 x 455mm
Net weight: 40KG
Gross weight: 42kg
Three phase Gasoline Generators
Competitive price gasoline generators
Good quality gasoline generators
Popular gasoline generators
With CE, ISO9001 certificate
Generators adopt advanced technology in design. Adopt brushless, capacitance adjusting the voltage device. Provide stable voltage, avoid the job of boring maintain and change the carbon brush. DC output and double voltage output will be supported on request
| Model | 2500 | 3600 | 3800 | 5000 | 6500 |
| Frequency (Hz) | 50 | 50 | 50 | 50 | 50/60 |
| Max. Power (W) | 2200 | 2700 | 3000 | 4200 | 5400/5700 |
| Rated Power (Kw) | 2 | 2.5 | 2.7 | 4.0 | 5.0 |
| Rated Current (A) | 8 | 9 | 12.2 | 18.2 | 22.7 |
| Run Time (Hrs) | 15 | 10 | 7.2 | 8.0 | 8.2 |
| Engine Model | 168F | 168F | 170F | 188F | 188F |
| Mixed Gas. Oil | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline |
| Fuel Tank (L) | 15 | 15 | 25 | 25 | 25 |
| Displacement (cc) | 163 | 196 | 196 | 389 | 389 |
| Noise Level at 7m | 64/66 | 66/67 | 66/67 | 66/67 | 67/68 |
| Engine Type | 4 Stroke, Air cooled | 4 Stroke, Air cooled | 4 Stroke, Air cooled | 4 Stroke, Air cooled | 4 Stroke, Air cooled |
| Dimensions L*W*H (mm) | 600*450*450 | 600*450*450 | 670*520*520 | 670*520*520 | 670*520*520 |
| N. W/GW (Kgs) | 38.5/41.5 | 41.5/44.5 | 50/54 | 66/69 | 68/72 |
Honda engine drawing
