2inch(50MM) Diesel Water Pump/self-priming YL-DWP50
Negotiable
MOQ: 100 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YongLi
Model Number:
YL-DWP50
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4 Inch Single-cylinder Air-cooled Diesel Water Pump YL-DWP100NegotiableMOQ: 100 Sets -
2 Inch(50MM) High Pressure Diesel Water Pump YL-DHP50NegotiableMOQ: 100 Sets
-
Diesel Water Pump, 2 Inches, 50mm, 211ccNegotiableMOQ: 1000 Pieces
-
Diesel Water Pump,211cc, 2 Inches, 50mm, CENegotiableMOQ: 1000 Pieces
-
Diesel Water Pump,3 Inches, 80mm, 178FNegotiableMOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
YongLi
Model Number
YL-DWP50
Theory
Centrifugal Pump
Usage
Water
Power
Other, 2.8kw
Standard or Nonstandard
Standard
Fuel
Diesel
Pressure
High Pressure
Specifications
1.suction dia./discharge dia.:2inch2.suction head:7m
3.total head:26m
4.flow rate:500L/min
5.diesel engine:5HP, air-cooled
Highly effective mechanical seal made with special carbon ceramics provides extra durability.Strong and light weight aluminium alloy pump body.
Application:
1)irrigation of paddy field
2)pumping water from well
3)sprinking for irrigate the field.
4)feeding or draining water on fish farms
DIESEL WATER PUMP
| Model | YL-DWP50 |
| Suction port diameter | 2" |
| Discharge port diameter | 2" |
| Suction Head | 7m |
| Total Head | 26m |
| Flow Rate | 500L/min |
| Start Method | Recoil/Electric start |
| Fuel Tank capacity | 2.5L |
| Engine Model | YL170F |
| Type | single-cylinder ,Vertical,air-cooled ,4-stroke,Direct Injection |
| Engine speed | 3600rpm |
| Rated output | 2.8kw |
| BorexStroke | 70x55mm |
| Displacement | 211cc |
| Lube-oil Capacity | 0.75L |
| Net weight | 30kgs |
| Dimension | 540x420x510mm |
diesel engine
| MODEL | YL170F |
| TYPE | single-cylinder vertical 4-stroke direct injection air-cooled |
| Crankshaft direction | clockwise from flywheel end |
| Cooling type | force air-cooled |
| Lubrication type | pressure splash |
| Start mode | recoil/electric start |
| Engine speed | 3600rpm |
| Consumption rate of fuel | ≤280g/kw.h |
| Consumption rate of machine oil | ≤4.08g/kw.h |
| Rated output | 2.8kw |
| BoreXstroke | 70x55mm |
| Compression ration | 20 |
| Displacement | 211cc |
| Fuel tank capacity | 2.5L |
| Lube-oil capacity | 0.75L |
| Packing | carton box |
| Net weight | 27kgs |
| dimensions | 415x345x455mm |
