Specifications
Open type Diesel Generator1. CE approved, powered by advanced air-cooled kama engine.
2. Noise-reducing enclosure
| Model | YL-D7500ALE | |
|
| Rated frequency (Hz) | 50 | 60 | |
| Rated voltage (V) | 220, 230, 240, 220/110, 230/115, 240/120 | ||
| Rated output power (KVA) | 5.5 | 6 | |
| Rated rotation speed (rpm) | 3000 | 3600 | |
| DC output | 12V, 7A | |
|
| Power factor cosφ | 1 | |
|
| Phase number | Single phase | |
|
| Excitation mode | Self-excitation Brushless | ||
| Noise level dB(A)@ 7m (zero load - full load) | 72 | ||
| Overall dimension [mm(in)](L× W× H) | 925× 520× 740 | |
|
| |
|||
| Net weight kg | 160 | |
|
| Structure model | Low noise type with enclosure | |
|
| Connection mode | Single bearing, rotor drive shaft, rigid coupling | |
|
| Engine model | 188F | |
|
| Engine type | 1-cylinder, 4-stroke, air-cooled, direct injection, diesel engine | |
|
| Displacement [cm³ (Cu-in)] | 456 (24.78) | |
|
| Compression ratio | 19: 01 | |
|
| Rated power [KW(Hp)/rpm] | 6.8(7.6)/3600 | |
|
| Starting system | Electric starting | |
|
| Rotation direction (view from flywheel) | Clockwise | |
|
| Fuel type | 0 (sumber), 10 (winter) diesel oil | |
|
| Lube | SAE10W30 (above CC grade) | |
|
| Low oil pressure alarm system | With | ||
OPITION:
ATS (With the city electric grid, the generators automatically switch to automatic control box to start generating and with the normal power supply when net power off. City electricity to be restored, the automatic switch box automatically switch to the city and the normal electric power supply, standby generator in the state
Digital display: display time.frequemcy.voltage,amp,etc.
Silent Diesel Generator
1. CE approved, powered by advanced air-cooled diesel engine.
2. Noise-reducing enclosure, made of high-efficient noise-proof material.
3. Ideal for home emergency use or as standby power supply.
4. Large fuel tank, ensuring hours of continuous output.
5. Advanced direct fuel injection system.
6. Large silent muffler & air-cleaner, reducing exhaust and intake noise.
7. A variety of specially-designed control panels available for different markets
Diesel engine drawing and CE certificated
