Silent Diesel Generator 5kw With Kama Engine
Negotiable
MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YOLEE
Model Number:
YL-DG6600SE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
YOLEE
Model Number
YL-DG6600SE
Output Type
AC Single Phase
Speed
3000rpm/min
Frequency
50HZ
Rated Power
5KW
Rated Voltage
220V
Rated Current
22A
Specifications
Diesel GeneratorAir-Cooled Diesel Generator1. 5KW diesel generator set, silent type.
2. With electrical start,
Diesel GeneratorAir-Cooled Diesel Generator
1. 5KW diesel generator set, silent type.
2. With electrical start,
3. With CE certification.
4. Manufacturer's price
. With CE certification and so on
2. We produce engine more the 10 years
3. Our AVRs are more steady
4. Our productions range from 2KW to 6KW
5. Our dynamotors are 100% copper
6. We can Design and increase ATS, digital panel, three phase, type output and any other equipment you need.
7. Our guarantee is 1 years.
8. Our engine passed the continual500 hours
Advantage:
Features: High thermal efficiency, Flexible, easy maintenance
Scope: Emergency supply power for small office and home
| Model | YL-DG6600SE | |
|
| Rated frequency (Hz) | 50 | 60 | |
| Rated voltage (V) | 220, 230, 240, 220/110, 230/115, 240/120 | ||
| Rated output power (KVA) | 4.5 | 5 | |
| Rated rotation speed (rpm) | 3000 | 3600 | |
| DC output | 12V, 7A | |
|
| Power factor cosφ | 1 | |
|
| Phase number | three phase | |
|
| Excitation mode | Self-excitation Brushless | ||
| Noise level dB(A)@ 7m (zero load - full load) | 70-74 | ||
| Overall dimension [mm(in)](L× W× H) | 920× 520× 700 | |
|
| 36.22× 20.47× 27.56 | |
||
| Net weight [kg(lbs)] | 140 (308) | |
|
| Structure model | Low noise type with enclosure | |
|
| Connection mode | Single bearing, rotor drive shaft, rigid coupling | |
|
| Engine model | 186FE | |
|
| Engine type | 1-cylinder, 4-stroke, air-cooled, direct injection, diesel engine | |
|
| Displacement [cm³ (Cu-in)] | 406 (24.78) | |
|
| Compression ratio | 19: 01 | |
|
| Rated power [KW(Hp)/rpm] | 6.3 (8.6)/3600 | |
|
| Starting system | Electric starting | |
|
| Rotation direction (view from flywheel) | Clockwise | |
|
| Fuel type | 0 (sumber), 10 (winter) diesel oil | |
|
| Lube | SAE10W30 (above CC grade) | |
|
| Low oil pressure alarm system | With | ||
Diesel engine drawing and CE certificated
