Fiberglass reinforced rod
Specification :
Technical Date of Fiberglass Duct Rodder | ||
Specification | Rod Diameter (mm) | Φ4.5,Φ6,Φ8,Φ10,Φ11,Φ12,Φ13,Φ14,Φ15,Φ16 |
Rod Length (m) | 50m~350m | |
Frame Spec.(mm) | 1300x450x1330,1200x420x1220,980x350x1000,680x240x700,420x180x400 | |
Material: | Fiber glass rod inner, | Extruded by fiber glass and high strength resin at high temperature |
Fiber glass rod outer | High Density polyethylene coating | |
Metal Frame | Steel with high-temperature sprayed plastic or hot dip galvanized | |
Physical Property | Fiber glass content | 75-80% |
Density | >1.9gr/cm3 | |
Working environment | -40°C to +80°C | |
Minimum Pulling strength | 4000N +/-5% | |
Consistency of rod | 137gr/m | |
Flexural Modulus | >46.500Mpa | |
Elongation at break | 2.5-3% | |
Min Bending Radius | 388mm | |
Features:
1. Strong non-conductive fiberglass rod construction.
2. Stainless steel drawing head.
3. For longer conduit runs and underground duct.
4. Rugged tubular steel reel with adjustable position.
5. Feed device allows rod to feed out or be wound back onto reel with easy push or pull of rod.
6. Duct rods/duct rodders have many applications which is not only pulling the cable but also pulling electric tools and its repair is very easy and available.
Applications:
This kind of products can be used for telecom cables, cable pipe and cleaning and plastic pipe of cloths to put.
When using draws out the FPR pole by the pulley, then with a corresponding metal joint, penetrates in the pipeline.
When cleaning, guide head will drive cleaning tools to clean the pipe; When arranges the cable, you may first leads the
steel wire or the iron wire, then enters the pipe with the steel wire or the iron wire hauling cable.
Product pictures:
Packing And Shipping Detail
Model Number | FDR |
Dimensions | Dia.4.5mm to 16mm |
Minimum Order Quantity | 2set |
Length | 10-400m |
Colour | As your request |
Port | Xin gang |
If you have any problem please contact us without hesitate .We will do our best to sevice for you
For further information, plz feel free to contact me: Skype: fan.kylin
We promise that we would provide the most qualified products with most favorable price. Please feel free to contact me if you are interested.
Look forward to contacting us and wish we could reach a deal ASAP.
All the listed price is reference ,for latest price please contact directly
