High Quality Plastic Polyhedral Hollow Ball For Exhaust Gas Purification Tower Use

Specifications

Plastic Polyhedral Hollow Ball
1.20 years professional manufacturer
2.Size:25,38,50,76,100
3.Material:PP,PE,PVC,PVDF

High Quality Plastic Polyhedral Hollow Ball For Exhaust Gas Purification Tower Use





Plastic Polyhedral Hollow Ball is made of standing up to chemical corrosion materials, such as polyethylene(PE),  polypropylene (PP),reinforced polypropylene(RPP),polyvinyl chloride(PVC), chlorides polyvinyl chloride(CPVC) and polyvinylidene fluoride(PVDF).



It has features such as high free volume, low pressure drop, low mass-transfer unit height, high flooding point, uniform gas-liquid contact, small specific gravity, high mass transfer efficiency and so on, and the application temperature in media ranges from 60 Degree C to 150 Degree C. For these reasons it is widely used in the packing towers in petroleum industry, chemical industry, alkali-Chloride industry, coal gas industry and environmental protection, etc..

The Advantages of Plastic holyhedral hollow ball:

• High free volume
• Low pressure drop
• Low mass transfer unit height
• High flooding point
• Uniform gas-liquid contact
• Small specific gravity
• High mass transfer

Applications of Plastic holyhedral hollow ball:

• Widely used in petroleum, chemical, alkali-chloride, coal gas and environmental protection.
• Application temperature in media ranges from 60 to 150 degrees



Physical & Chemical properties of plastic tower packing

Performance / Material	PE	PP	RPP	PVC	CPVC	PVDF
Density (kg/m3)	0.94-0.96	0.89-0.91	0.93-0.94	1.32-1.44	1.50-1.54	1.75-1.78
Operation Temp.(Degree C)	90	>100	>120	>60	>90	>150
Chemical corrosion resistance	Good	Good	Good	Good	Good	Good
Compression Strength(Mpa)	>6.0	>6.5	>7.0	>6.0	>8.0	>10.0



Technical Data for Plastic Polyhedral Hollow Ball Packing

Specification (mm)	Surface area (m²/m³)	Free volume (%)	Bulk density (kg/m³)	Number per m³
ø25	460	84	145	64000
ø38	325	87	125	25000
ø50	236	90	105	11500
ø76	150	92	90	3000



Package Type	Container Load Capacity			Delivery time	Quality  Insurance	Payment Terms
	20 GP	40 GP	40 HQ
Ton bag	20-24 m3	40 m3	48 m3	Within 3-10 days	Chinese National Standard;  Offer quality assurance  as request.	T/T, L/C,  Paypal,  West Union
Plastic bag	25 m3	54 m3	68 m3
Paper box	20 m3	40 m3	40 m3
