SYCH series trough mixer for powder
Brief introduction:
This machine is used to mix powder or paste material, make different qualitative material mixing.Characterized by horizontal trough the single oar mix, beater blade for shaft, easy to clean.Contact with the object in all adopt stainless steel, has the good corrosion resistance, the mixing tank can automatically turning down the material.
The main technical parameters:
model | SYCH100 | SYCH200 | SYCH300 | SYCH400 | SYCH500 |
volume | 100L | 200L | 300L | 400L | 500L |
Stirrer speed | 24r/min | 24r/min | 24r/min | 24r/min | 24r/min |
Mixing tank flip Angle° degrees | 360° | 360° | 360° | 360° | 360° |
Mixing tank turning speed | 9r/min | 9r/min | 9r/min | 9r/min | 9r/min |
Main motor power | 1.5kw | 4kw | 5.5kw | 5.5kw | 7.5kw |
Vice motor power | 0.75kw | 1.1kw | 1.1kw | 1.1kw | 1.5kw |
Overall dimensions | 1380 * 500 * 900mm | 1670*600*1150mm | 2150*700*1250mm | 2280*800*1250mm | 2400*900*1250mm |
Weight | 270kg | 600kg | 750kg | 780kg | 820kg |
