SYXD-1600BL Bottom Loading furnace with high temperature
- 70 Set / Sets per Month
- qingdao/guangzhou/ningbo
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Resistance Furnace | |
| Usage | Muffle Furnace | Place of Origin | Henan, China | |
| Brand Name | SAIYE | Model Number | SYXD-1600BL | |
| Voltage | 380V | Power(W) | 9000 | |
| Dimension(L*W*H) | 700*800*1600 mm | Weight | 300 kg | |
| Certification | ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
SYXD-1600BL Bottom Loading furnace with high temperature
SYXD1600BL The single zone, high temperature, bottom loading furnace is capable of operating at temperatures up to 1650oC in air. The furnace utilizes 1800oC molydisilicide heating elements positioned on three sides of the internal chamber. The furnace utilizes an energy efficient insulation package consisting of graded ceramicfiber, high temperature insulation. It is an ideal tool for materials annealing and sintering.
Techncial paramter:
Inside Chamber Size | 200 x 200 x 200 mm (8"x8"x8", 8 Liter) |
Standard Working Temperature | 1600oC ( continuous ) |
Maximum Working Temperature | 1700oC ( < 3 hrs) |
Temperature Control | 30 steps programmable and PID automatic control |
Heating Rate | 0~ 10.C/ min (suggestion: =< 10.C ) |
Temperature Accuracy | +/- 1 .C |
Heating Element | MoSi2 heating elements |
Working Voltage | AC 380V Three Phases 60/50 Hz (or according to your requirement) |
Max. Power | 9 KW |
Outside Size | 700 x 800 x 1600 mm |
Net Weight | 300 Kg |
Standard Sizes:
Model | Chamber size(WxHxDmm) | Max. Temperature |
XD-1600BL | 150x150x 150mm (6"x6"x6") | 1650.C |
XD-1600BL | 150x150x 200mm (6"x6"x8") | 1650.C |
XD-1600BL | 200x200x 200mm (8"x8"x8") | 1650.C |
XD-1600BL | 200x200x 300mm (8"x8"x12") | 1650.C |
XD-1600BL | 250x250x 300mm (10"x10"x12") | 1650.C |
XD-1600BL | 300x300x 400mm (12"x12"x16") | 1650.C |
XD-1600BL | 400x400x 400mm (16"x16"x16") | 1650.C |
XD-1600BL | 500x500x 500mm (20"x20"x20") | 1650.C |
