Home > Industrial Equipment & Components > Valve > Ball Valve > Class 150-300 Butterfly Swing Check Valve

Class 150-300 Butterfly Swing Check Valve

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Check

Pressure:

Medium Pressure

Contact Supplier Request Quote Chat Now

Yongjia Welldone Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Check

Pressure Medium Pressure

Power Hydraulic

Material Forged

Temperature of Media Medium Temperature

Media Water

Place of Origin Zhejiang, China

Brand Name WD

Specifications

Class 150-300 Butterfly Swing Check Valve

Specifications

Butterfly Swing Check Valve
1. Sizes: 2" to 24"
2. Design: API 600, API 6D, BS1414. JIS, DIN.
3. Materials: CI

Class 150~300 Butterfly Swing Check Valve
Standards Compliance:
Design and Manufacture: ANSI B16.34, API 6D
Face to face: API 6D
Flanged connection: 2"~24"to ANSIB16.5, 22", 26"~36"to MSS-SP-44 to API605 on Request
Test and inspection: API 6D
Shell test 150Lb 450 PSI
300Lb 1125 PSI
Seat test 150Lb 315 PSI
300Lb 815 PSI(Hydrostatic)80PSI(Air)

Features:
1. Small in size, light in weight, compact in structure, easy in maintenance.
2. Two torsion springs are used excreting on each of the pair valve plates. Which close the plates quickly and automatically.
3. The quick-close action prevents the medium from flowing back and eliminates water-hammer effect.
4. This valve is short in length, so that it is rigid and easy to mount.
5. It is easy to install on pipeline which is laid horizontally or vertically.
6. This valve is tightly sealed without leakage under the pressure water test.
7. Safe and reliable in operation, high interference-resistance.
8. The connection dimensions of flanges accord with the standards of GB4216-84 GB4216.84
9. The face to face dimensions are in accordance with GB12221-89. ISO5752-82. The stem of the valve should be perpendicular to the horizontal level when the valve is mounted on horizontal pipeline. For vertical installation the direction of flow should be downward .
