LPG Mini Skid WD-MS-LPG222(2 flowmeter-2 nozzle-2 displays-2 keyboard)
LPG Mini Skid WD-MS-LPG222
(2 flowmeter-2 nozzle-2 displays-2 keyboard)
External Dimension:1050x1050x1600
Technical Specification:
Ambient Temperature:-40°C~55°C
Power:AC380V±20% (50±1Hz)
Flow Rate:1~45 Liter/min
Measurement presicion:±0.5%
Rated Working Pressure:1MPa
Density Preset Range:0.5000-0.6999
Gas-filling Preset Range:1~9900L or kg
Rating Power:4KW
Unit Price Range:0~9999, 0~999999(changeable)
Single Range:1~9900.00, 1~999900.00(changeable)
Accumulative Range:0~9999999999.99
ATC(Automatic Temperature Compensation) Function.
Automatic Proportion Adjust for Butane and Propane.
Electronic Calibration.
Printer(Option).
Fueling Times Limit Function.
Stop Fueling By Integer Sale.
Can Set the decimal point for the display,so can be used in many country with different currency rate.
Leaves the communication ports,so it can communicate with the gas station management system .
Connection Diagram:
