Power | selection Pump | Pressure (kg/cm²) | Style | Output L/min | weight (kg) | Volume (mm) |
168F-1(6.5HP) | 3WZ-36 | 20-40 | Stretcher type | 30-52 | 33 | 800*350*450 |
Application:
Widely used in farmland , orchards , gardens , vegetable base rule controlling pests , water pumping , spray irrigation , etc. , can also be used in public places , such as cleaning and garbage site disinfection spray medicine .
1 Please check carefully before starting each of the fasteners are tightened to ensure that sprayer and motor are mounted on a tripod ;
2 Adjust the drive belt and two pulleys to a parallel state , elastic medium ;
3 Each locking tube connector to prevent leakage ;
4 Turn off the water before starting the motor switch , loosen the screw regulator , the regulator handle is pulled to the top ;
5 The starter motor drive unit to maintain an appropriate rotational speed , the pressure in the end and handle end of the regulator to adjust the pressure regulator to keep the wheel in between 1.0-3.0MPa , the switch opens the water spray began to work properly ;
6 Using the method according to the different needs and sprinklers , ibid method of adjusting to normal operating pressure.
