2000kg Capacity Front Loader With Air Condition,Preheat System & Joystick

Jinan Aos International Trade Co., Ltd.

US$ 9,000 - 14,500 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

AOS

Model Number:

SY920

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name AOS

Model Number SY920

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 6000*2100*2950mm

Rated Load 2000kg

Certification ISO9001/CE

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Wheel Loader:

Specifications of 2000kg loader:

Performance:	Rated load	2000kg
	Bucket	2200mm, ≥1.35m³,lateral teeth as required;
	Max.Gradeability	25°
	Dumping Height	3200mm
	Dumping Reach	950mm
	Raising Time	≤ 5.0s
	Total Cycle Time	≤ 11s
	Min.Turning Radius	4500mm
	Overall Dimensions	600021002950mm
	Total weight	6000kg
Engine:	Model	Quandong brand
	Type	In-line,Water-cooled,4-stroke,Direct injection
	Rated Power	55kw
	Rated Speed	3600 rpm
Gear box:	Torque Converter	Hydraulic Integrated Type
	Gear Shift	2 forward,2 backward
	Max.Speed	25 km/h
Drive Axle:	Model	Isuzu technology axle, bigger type
	Wheel Base	2200mm(axle distance)
	Wheel tread	1600mm (wheel center distance);
Drive:	Mode	4-way Drive
Hydraulic System:	Working Pressure	16Mpa
Brake system:	Service Brake	Sing line,Hydraulic,Expansion-shoe Brake on 4 wheels
Brake system:	Parking Brake	Hand Flexible Shaft Control Disk Brake
Tyre:	Type Specification	16/70-24
	Front Tyre Pressure	0.5 Mpa
	Rear Tyre Pressure	0.48 Mpa
Added devices:	air condition,preheat system& joystick.
