Help CenterCNC Router for Foam and Wood Mould Z Aisx 600-1200mm Cyntec Control System
Related Products
-
Multipurpose Stone Engraving Machine Dual Purpose Cutting And Engrave CNC Stone MachineUS$ 7,000 - 12,000MOQ: 1 Set -
Hot Sale 2 Spindles Wood Working Cutting and Engraving Machine Size Can be OrderedUS$ 4,000 - 7,000MOQ: 1 Set
-
Two Header Stone Engraving Machine CNC Stone Machine With DSP Control SystemUS$ 7,000 - 12,000MOQ: 1 Set
-
CNC Plasma Cutting MachineUS$ 5,000 - 6,000MOQ: 1 Set
-
Chinese Cheap CNC Plasma Cutting Machine Cutting Thickness Max Of 10mmUS$ 5,000 - 6,000MOQ: 1 Set
Standard Features:
1. Whole machine is welded with seamless steel structure and been vibration aging treatment; steel gantry which the stability is excellent, not easy to be deformed.
2. Three axes adopt imported HIWIN square guiding rail; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost. Z axis adopts high-precision ball screw,with high precision and long life time.
3. Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai etc.
4. Has the function of re-carving after break point and power failure.
5. Has the function of forecasting process time.
6. Adopting advanced Nc studio system with USB connection, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources.
7. Perfect oil-inject system makes maintenance much easier.
8. Adopting water cooling system, it can provide good cooling effect when carving flinty materials.
9. Dustproof design for the machine protects the transmission parts from broken:
10. Fumigation-free wooden case.
Applicable industries
Molds industrial: It engraves all kinds of large nonmetallic molds, especially automotive foam molds, wooden ship molds, aviation and train wood molds. And wood mold casting, food mold (such as moon cake mold) and other precision mold making.
Technical Parameter:
Description | Parameter |
X,Y Working Area | 1500*3000mm |
Z Working Area | 800mm |
Table Size | 2050*3680mm |
Package size | 2200*3900*2200mm |
Resolution | 0.1mm |
Lathe Structure | Seamless welded steel structure |
X,Y Structure | Rack and pinion transmission, |
Imported HIWIN guiding rail | |
Z Structure | Ball screw |
Max. Idling Speed | 35m/min |
Spindle Motor Power | 9.0 Kw spindle |
Spindle Rotate Speed | 0-18000r/min |
Working Voltage | AC380V/50Hz |
Working Mode | servo |
Command | G code,HPGL,U00,mmg,plt |
Operating System | Cynteccontrol system |
Diameter of cutter | φ3.175-φ24mm |
Cooling Mode | Water-cooling |
Work-holding | By clamp |
Net Weight | 1800KG |
Gross Weight | 2100kg |
