Performance 1. four axis machine, with 4 Rotaries and 4 spindles, which can work at the same time or independently, and every one's max effective working area is 150mm(diameter) by 1000mm(length). 2. With Scanner or designed photo, it can do any 3D Engraving and 2D Engraving . 3. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed. 4.Has the 4th rotary which is used for engraving cylinder workpiece. 5.Well compatibility: CAD/CAM designing software e.g. Type3/Artcam/ Castmate/Wentai etc. 6.Has the function of re-carving after break point and power failure 7. Adopting advanced YASAKWA servo motor and NC studio control system Main components of this machine 1 Spindle motor: Domestic 2.2KW water-cooled spindle 2 Motor system:Japan YASKAWA servo motor 3 Operating system: NC studio system 4 Inverter: Fuling 5 Rail: Taiwan HIWIN square rails, lubrication-free lifelong 6 Beam: steel beam stiffeners 7 Cable: drag chain specific Cable, antijamming, antistatic; with high flexibility, longterm use will not break 8 Limit switch: Japan OMRON 9 Electrical components: Schneider and Siemens 10 Table: overall welding tempered aging treatment, strong and does not distort |
Parameter
Description |
Parameter |
X,Y,Z Working Area |
1300x2500x200mm |
Table Size |
1640×3040mm |
X,Y,Z Traveling Positioning Accuracy |
±0.03/300mm |
X,Y,Z Repositioning Accuracy |
±0.03mm |
Table Surface |
Vacuum and T-slot working table (Option: T-slot Table ) |
Frame |
Welded Structure |
X, Y Structure |
Rack and Pinion Drive, Hiwin Rail Linear Bearings |
Z Structure |
Hiwin Rail Linear Bearings and Ball Screw |
Max. Power Consumption |
(Without Spindle) 9Kw |
Max. Rapid Travel Rate |
33000mm/min |
Max. Working Speed |
25000mm/min |
Spindle Power |
2.2kw water cooling spindle |
Spindle Speed |
0-24000RPM |
Drive Motors |
stepper |
Working Voltage |
AC380V/50/60Hz,3PH (Option: 220V) |
Command Language |
G Code |
Operating System |
DSP System (Options: Ncstudio/Mach3 PC Software) |
Computer Interface |
USB |
Flash Memory |
128M(U Disk) |
Collet |
ER25 |
X,Y Resolution |
<0.01mm |
Software Compatibility |
Type3/Arcam Software |
Running Environment Temperature |
0 - 45 Centigrade |
Relative Humidity |
30% - 75% |
Packing Size |
3100X2100X1900mm |
N.W. |
1350KG |
G.W. |
1500KG |
Optional Parts |
Water Cooling Spindle |
Syntec Control System | |
Dust Collector | |
Rotary System | |
Mist-cooling System | |
Yaskawa DELTA Servo Motors |
