Model:Welded wire mesh machine
Production details:
Welded wire mesh machine host, terrific, electric control cabinet, mending
the nets machine, mending the nets and Taiwan and playing machine composition,
weft wire and wire diameter are from the feed. Raw material is low carbon steel
wire and stainless steel wire. The machine is designed with advanced and
reasonable design, low noise, good stability, easy to operate and electromagnetic
speed control. The mesh is accurate, the width of the welded wire mesh machine.
Applicable:
The machine can be used to screen, corn, animal cage net, breeding net,
net garden, building net.
The main parameter:
| Net width | 914.4mm;1000mm | 1219mm;1524mm | 1219mm;1524mm | 1919.2mm;1524mm;1828.8mm;2133.6mm |
| mesh | 6.35-12.7mm(1/4"-1/2") | 19.05mm(3/4") | 12.7-1.106mm | 25.4-101.6mm(1"-4") |
| wire diameter | 0.4-0.65mm | 0.6-1.4mm | 0.6-1.8mm | 1.2-2.5mm |
| Voltage | 380V 50HZ | 380V 50HZ | 380V 50HZ | 380V 50HZ |
| power of motor | 2.2KW | 2.2KW | 2.2KW | 4.0KW |
| welding speed | 75times/min | 120times/min | 120times/min | 80times/min |
| external dimensions | 2.3*1.3*1.4m | 3.0*1.75*1.65m | 2.0*1.50*1.6m/3.0*1.75*1.65m | 2.0*1.50*1.6m/3.0*1.75*1.65m |
| weight | 1.5T | 2.5T | 2.0T;2.5T | 2.0T;2.5T;3.0T;3.5T |
| Transformer power | 50KVA*3 | 65KVA*5 | 65KVA*4/65KVA*5 | 65KVA*4/65KVA*5 |
Related machine:
Contact:Gail
Tel:86-18031855078
Fax:86-031185245076
Whatsapp/wechat:+18832128285
QQ:2746862612
