China Brand Construction Machinery Pneumatic Road Roller 26000kg

LRS226-2 Pneumatic Tire Rollers

Pneumatic smooth-tire rollers is suitable for compaction of various cohesive and non-cohesive materials such as sandy soil, crushed stone, stabilized soils, bituminous concrete and rolling cement concrete(RCC) on road surface construction, especially for final compaction of asphalt surface on high-class highway, which is super quality compaction equipments for high-class highway, airport, municipal road and industrial ground.

Main Features

1.Famous brand water-cooled turbocharged diesel engine with advanced performance.

2.Hydrodynamic transmissions promotes pavement compaction quality. Electronic operation of the power gearshift with flexibility.

3.Power sprinkler system with three-stages filtering and high water pressure by using the reciprocal diaphragm electric pump. Three-stage braking system is credibility and stabilization.

4.Graceful grand arc streamline style outline, specially-made combination instrument table and adjustable steering wheel and seat are concentrated in the spacious closing operator's cab with wide vision.

5.Infrared compaction video monitor system and backup buzzer are greatly convenient for driver's travel and working controls.

6.Whole floating structure front wheels, rear wheels and main driving components are designed modularly, which can be interchanged more convenient maintenance.

TECHNICAL SPECIFICATIONS

Model: LRS226-2

Max.operating mass: 26000kg

Min.operating mass: 16000kg

Max.travel speed: 20km/h

Tire number: 5+6

Tire contact pressure: 250~420kPa

Turning radius: 8300mm

Rolling width: 2790mm

Wheel overlap: 40mm

Gradeability: 20%

Diesel model: Cummins6BT5.9

Diesel power: 110kW

Diesel speed: 2300r/min.

Overall dimensions(with cabin): 4874×2790×3100mm

Overall dimensions(with canopy): 4874×2790×3192mm
