Help CenterQLY110 TRUCK CRANE
Related Products
Through our innovation and improvement ,QLY110 truck crane is ahead of domestic industry by its “ environment protection , safety , reliability and advanced” ,the product integrates the advanced design and manufacturing techniques at home and abroad .the product adopted full-head luxury chassis cabin, and superstructure integral operating cabin with large view, fully covered walking plate at the left side and right side, six-axle automobile chassis , driving type 12×8,five-section telescopic boom, 5-section hexagon large curve boom , double-cylinder front support luffing ,two-section jibs(truss type and box type),double H type outrigger and attached with the front 5th outrigger which can realizes 360°full slewing lifting work, the machine adopted the pilot handle control technique, so the machine has strong lifting performance and it is easy and flexible to operate the truck crane for user.
ITEM |
UNIT |
DATA |
|||
Dimension | |||||
Overall dimension(L*W*H) |
mm |
16050*2900*3990 |
|||
Outrigger longitudinal span |
mm |
7700 |
|||
Outrigger transversal span |
mm |
7600 |
|||
Weight | |||||
Total weight in travel |
kg |
71000 |
|||
Axle load |
kg |
Front :11500*2/Rear:12000*4 |
|||
Engine | |||||
Engine model |
|
BENZ OM502LA.III/1 |
|||
Engine rated power |
HP/(r/min) |
476/1800 |
|||
Engine rated torque |
N.m/(r/min) |
2300/1080 |
|||
Working performance specifications | |||||
Max. rated lifting capacity |
kg |
110000 |
|||
Lifting moment for basic boom |
KN.m |
3234 |
|||
Boom lifting height |
m |
50.2 |
|||
Jib lifting height |
m |
67 |
|||
Single line speed |
m/min |
75 |
|||
Slewing speed |
r/min |
2 |
|||
Travelling specifications | |||||
Max. travelling speed |
Km/h |
70 |
|||
Max. grade ability |
% |
35 |
|||
Min. turning radius |
m |
12 |
|||
Min. ground clearance |
mm |
300 |
|||
Approach angle |
° |
21 |
|||
Departure angle |
° |
14 |
|||
