BG-F-020/026 Series Agricultural Gearbox
US$ 100 - 180
MOQ: 100 Sets
Key Specifications
Get Latest Price
Brand Name:
BOWIN
Model Number:
BG-F-020/026
Gearing Arrangement:
Bevel / Miter
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BG-F-027/029 Series Agricultural GearboxUS$ 60 - 150MOQ: 100 Sets -
BG-F-030/034 Series Agricultural GearboxUS$ 30 - 350MOQ: 100 Sets
-
BG-F-035/036 Series Agricultural Gearbox OEMUS$ 35 - 180MOQ: 100 Sets
-
Wing Type Agricultural Gearbox OEMEUR 100 - 150MOQ: 100 Sets
-
Gearbox for Rotary CutterEUR 100 - 300MOQ: 200 Sets
Brand Name
BOWIN
Model Number
BG-F-020/026
Gearing Arrangement
Bevel / Miter
Output Torque
85~120 NM
Rated Power
125 HP
Input Speed
540~1000RPM
Output Speed
850~1000 RPM
1. BG-F-020/026 Series Agricultural Gearbox
2. Ratio ranging at 1:1.35;1:1.56;1:1.28;1:1.69 and 1.18:1
3. Input Power: 125HP at 540/740/1000rpm
4. Output Torque: 85~120NM
5. Weight: 52.5kg.
This BG-F-020/026 series agricultural gearbox prodcuts is applied on finishing movers, rotary cutters, rotary slashers and tillage machinery, etc.
It's designed for OEM market and any modification with customer's drawings and specifications is possible.
The most prices and terms from Chinese suppliers.
This model is quite similar to COMER gearbox LF-223J.
