Help CenterPlanetary Gear
US$ 3 - 50
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Nonstandard
Tooth Profile:
Other
Material:
Other, Steel, 20MnCr5, 8620H, 20CrMoH, 18CrNiMo5
Payment & Shipping
Payment Methods:
Port of Shipment:
Chinese port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Nonstandard
Tooth Profile
Other
Material
Other, Steel, 20MnCr5, 8620H, 20CrMoH, 18CrNiMo5
Processing
Other, Hobbing+Shaving
Pressure Angle
20-28
Model Number
BWS66420106
Brand Name
BOWIN
BWS66420106 Planetary Gear can be manufactured according the design from customers.
We are one of the main suppliers for Bonfiglioli Group.
The involute teeth M2.25 Z18 is made by hobbing and shaving, with excellent control on the deformation during heat treatment, the precision level reaching DIN 3962-3963 class 8. Roughness on inner hole surface is at Ra 0.4, and Ra 0.8 on teeth surface.
Number of teeth: 18
Standard module:2.25
Standard pressure angle: 20
Tip diameter:46.9
Root diameter:36.231
DIN 3692-3693 class 8
1.Planetary Gear for Construction
2.Material:20MnCr5, 20CrMoH, 8620H,18NiCrMo5
3.Hardness:60-62 HRC
4.Core hardness:36 HRC
