Shaving Teeth Planetary Gear
EUR 3 - 15
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Nonstandard
Tooth Profile:
Other
Material:
Other, Steel, 20MnCr5, 8620H, 20CrMoH, 18CrNiMo5
Payment & Shipping
Payment Methods:
Port of Shipment:
Chinese port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Nonstandard
Tooth Profile
Other
Material
Other, Steel, 20MnCr5, 8620H, 20CrMoH, 18CrNiMo5
Processing
Other, Hobbing + Shaving
Pressure Angle
20 Degree
Model Number
BWS66420107
Brand Name
bowin
Shaving Teeth Planetary Gear manufactured according the design from customers.
The outer teethM2.5 Z26 is made by hobbing and shaving,the inner involute spline hole is made by broaching and slotting.we are quite confident to have excellent control on the deformation during heat treatment.
Number of teeth: 26
Standard module:2.5
Standard pressure angle: 20
Tip diameter:72
Root diameter:60.092
DIN 3692-3693 class 8
1.Shaving Teeth Planetary Gear is supply for OEM
2.Material:20MnCr5, etc.
3.Hardness:60-62 HRC
4.Roughness: Ra 0.8
5.Core hardness:36 HRC
