Help Center2YA2460 Circular Vibrating Screen
Related Products
-
High Frequency YA Series Hot Sae Vibrating Screen in ChinaUS$ 12,000 - 13,000MOQ: 1 Set -
Changzhou AMEC Brand Good Quality Vibrating Screen for MiningUS$ 6,500 - 7,000MOQ: 1 Set
-
Vibrating Screen for Stone Crushing PlantUS$ 7,000 - 8,000MOQ: 1 Set
-
Vibrating Screen/vibration Screen Supplier,vibrating Screens ManufacturersUS$ 11,000 - 12,000MOQ: 1 Set
-
Vibrating Screen for Aggregate, Crushed Limestone Screen MachineUS$ 12,500 - 13,000MOQ: 1 Set
YA Circular Vibrating Screen is a type of new type screen machine, with a elliptical vibration. It’s designed for quarry to process stone material, can also be applied in coal dressing, beneficiation, building materials, electric power and chemical industry. It is also of reliable structure, strong exciting force, high screening efficiency, low vibrating noise, long durability, convenient maintenance, safe operation, etc., and uses eccentric block to produce strong exciting force. Crossbeam and the main body of the screen are connected with high strength screw bolts. So they have the features of simple structure and easy maintenance. It adopts tire clutch with capability of flexible connection and stable operation, structure of small amplitude, high frequency, large obliquity to make the screen hold the capability of high efficiency, large handling capacity, long life span, low consumption, little noise. It’s applied in mining, building materials, transportation, energy, chemical industry to screen material, and it’s the ideal machine in crushing production line.
Raw Materials:
granite, marble, basalt, iron ore, cobble, shale, bluestone, coal, cobblestone, construction waste
Application:
mining, building materials, transportation, energy, chemical and other industrial
Advantages of Circul Vibrating Screen
1. Longer service life, little noise, stable resonance region.
2. High quality motor makes sure stable working of machine.
3. Easy to maintain.
4. Longer service life, hard to plug hole.
Working Principle of Circul Vibrating Screen
Motor drives vibration exciter eccentric block high-speed rotating. Straining box will be forced to do circular motion, material on the screen will be forced to do throwing motion, standard materials go thourgh screen and whole process will be completed.
Specification and Technical Parameter of Circul Vibrating Screen
| Model | Layer of Screen |
Size of Sieve Pore(mm) |
Max . Feeding Size (mm) | Capacity(m3/h) | Double Amplitude (mm) |
Model of Motor | Motor Power(kw) | Screen Model Specification(mm) |
Weight(t) | Dimension(mm) |
| 2YA1237 | 2 | 3-50 | 300 | 10-80 | 6-8 | Y160M-4 | 11 | 1200×3700 | 3.6 | 4600×1900×1200 |
| 3YA1237 | 3 | 3-50 | 300 | 10-80 | 8 | Y160M-4 | 11 | 1200×3700 | 3.9 | 4730×1900×1650 |
| 4YA1237 | 4 | 3-50 | 300 | 10-80 | 8 | Y160M-4 | 11 | 1200×3700 | 4.5 | 4900×1900×2150 |
| 2YA1548 | 2 | 3-100 | 300 | 22-160 | 8 | Y160L-4 | 15 | 1500×4800 | 4.6 | 5720×2260×1200 |
| 3YA1548 | 3 | 3-100 | 300 | 22-160 | 8 | Y160L-4 | 15 | 1500×4800 | 5.1 | 5900×2260×1650 |
| 4YA1548 | 4 | 3-100 | 300 | 22-160 | 8 | Y160L-4 | 15 | 1500×4800 | 5.6 | 6050×2260×2100 |
| 2YA1848 | 2 | 3-100 | 300 | 32-276 | 8 | Y180M-4 | 18.5 | 1800×4800 | 5.35 | 5720×2560×1200 |
| 3YA1848 | 3 | 3-100 | 300 | 32-276 | 8 | Y180M-4 | 18.5 | 1800×4800 | 6 | 5900×2560×1650 |
| 4YA1848 | 4 | 3-100 | 300 | 32-276 | 8 | Y180M-4 | 18.5 | 1800×4800 | 6.65 | 6050×2560×2100 |
| 2YA1860 | 2 | 3-100 | 300 | 65-586 | 8 | Y180M-4 | 22 | 1800×6000 | 6 | 6920×2560×1200 |
| 3YA1860 | 3 | 3-100 | 300 | 65-586 | 8 | Y180M-4 | 22 | 1800×6000 | 6.6 | 7100×2560×1650 |
| 4YA1860 | 4 | 3-100 | 300 | 65-586 | 8 | Y180M-4 | 22 | 1800×6000 | 7.2 | 7250×2560×2110 |
| 2YA2160 | 2 | 3-100 | 300 | 81-720 | 8 | Y200L-4 | 30 | 2100×6000 | 10.1 | 7020×3090×1320 |
| 3YA2160 | 3 | 3-100 | 300 | 81-720 | 8 | Y200L-4 | 30 | 2100×6000 | 11.3 | 7160×3090×1780 |
| 4YA2160 | 4 | 3-100 | 300 | 81-720 | 8 | Y200L-4 | 37 | 2100×6000 | 12.5 | 7320×3090×2230 |
| 2YA2460 | 2 | 3-150 | 300 | 90-810 | 8 | Y225S-4 | 37 | 2400×6000 | 11.6 | 7020×3390×1320 |
| 3YA2460 | 3 | 3-150 | 300 | 90-810 | 8 | Y225S-4 | 37 | 2400×6000 | 12.8 | 7160×3390×1780 |
| 4YA2460 | 4 | 3-150 | 300 | 90-810 | 8 | Y225S-4 | 37 | 2400×6000 | 14 | 7320×3390×2230 |
| 2YK2870 | 2 | 3-200 | 300 | 150-1000 | 8 | Y225S-4 | 37 | 2800×6500 | 13 | 7190×3630×1550 |
| 3YK2870 | 3 | 3-200 | 300 | 150-1000 | 8 | Y225S-4 | 37 | 2800×6500 | 14.5 | 7340×3630×2050 |
| 4YK2870 | 4 | 3-200 | 300 | 150-1000 | 8 | Y225M-4 | 45 | 2800×6500 | 15.8 | 7513×3630×2550 |
| 2YK3073 | 2 | 3-200 | 300 | 180-1300 | 8 | Y200L-4 | 30×2 | 3000×7300 | 24 | 7320×4628×4750 |
| 3YK3073 | 3 | 3-200 | 300 | 180-1300 | 8 | Y200L-4 | 30×2 | 3000×7300 | 25 | 7320×4628×5250 |
| 4YK3073 | 4 | 3-200 | 300 | 180-1300 | 8 | Y200L-4 | 30×2 | 3000×7300 | 26 | 7320×4628×5750 |
| 3EL1860 | 3 | 3-100 | 400 | 180-580 | 14-19 | Y200L-4 | 30×2 | 1800×6000 | 8.1 | 6942×3355×2055 |
Nude packing for the main machine
Wooden case for the power motor and spare parts
We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support and after service.
Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.
