AMEC Gold CIP/CIL Production Line , Gold Mining Processing Plant
- 1 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Gold mining jaw crusher equipment for sale, stone crusher machine
- First-rate high efficiency SZZ series self-centering vibrating screen with ISO 9001 Certificate
- China leader manufacturer ZHAOXIN high efficiency thickener
- Ore benefication thickener machine, dewatering thickener price
- china high quality center drive thickener, thickening equipment
- Shandong Province high efficiency center drive thickener NZ-12, thickening machine
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | AMEC | Model Number: | CIL/CIP |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CIL/CIP Gold Extraction Plant is widely used for rock gold ore with different grade. We have successfully set up the gold extraction plant in Phillipines, Columbia, Venezuela, Peru, South Africa, Sudan, etc
Gold processing CIP plant covers many gold mining equipment, such as feeder, crusher, ball mill, classifier, vibrating screen, rocking bed, magnetic separator, mix tank, leaching and cyaniding equipment, and other mining machineries.
Description of gold processing plant
1. The first step of gold processing plant if the extracted ore should be crushed by jaw crusher initially. When it gets the reasonable fineness, it is transported into ball mill by elevating conveyer and feeder, and is milled by ball mill.
2. After milling, the next step is classify. If the weights of solid particles are different, the sedimentations will be different, and the mixed ore can be classified by screw classifier. The classified ore gets into magnetic separator. Since the specific magnetization coefficients of ores are different, the magnetic substance of mixed ore is separated from others with magnetic and mechanical force.
3. Before the adsorption of cyaniding pulp, remove the wood chips to avoid it adsorbs the gold and blocks the carbon screen.
4. Adding carbon in the leaching tank; The carbon absorbs gold becoming gold loaded carbon. After adsorption, carbon screen separates the carbon and pulp.
5. Desorption electrolysis, under high temperature and pressure, gold loaded carbon separates gold mud and carbon in closed system
6. Smelting. After simple pickling and impurity removal, the gold ingots are obtained. This is the aim of gold processing plant.
Nude packing for the main machine
Wooden case for the power motor and spare parts
We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support and after service.
Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.
Our main scope of our business:
Machinery and Equipment:
Power machinery, agricultural machinery, garden machinery, construction machinery, mining machine,machine tools and complete equipment
Power Transmission Parts
Chains, sprockets, taper bushes, gears and shafts
OEM components:
Machined, forged, cast, punched and welded workpiece
Micro Motors
Step motors, DC brushed & brushless motors, AC motors for aircon and paper shredder
Automobile Accessories
Auto lens and lamps, mirrors, motors and mechanical parts
Keeping the customers satisfied has been our strong wish. Please contact us for more information. We welcome your orders
.
