Home > Manufacturing & Processing Machinery > Lifting Equipment > Lifting Table > Electric Order Picker
US$ 1,500 - 3,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
FOTMA
Model Number:
CQD0.75-2.7
Payment & Shipping
Payment Methods:
Port of Shipment:
Wuhan/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Hubei, China
Brand Name
FOTMA
Model Number
CQD0.75-2.7
Lift Mechanism
Articulated Lift
Lift Drive / Actuation
Electric Motor
Power
1.5kw
Rated Loading Capacity
750kg
Min. Lifting Height
515mm
Max. Lifting Height
2700mm
Table Size
700*800mm
Overall Dimensions
1600*930*1750mm
Weight
480kg
Specifications
Electric Order PickerRated capacity: 750kg, 300kg
Platform max.lifting height: 2700mm, 3000mm
Electric Order Picker
Specifications:
| Model | Unit | CQD0.75-2.7 | CQD0.3-3.0 |
| Rated capacity | kg | 750 | 300 |
| Platform max.lifting height | mm | 2700 | 3000 |
| Min.platform height | mm | 515 | 450 |
| Plaform size(1*W) | mm | 700*800 | 600*600 |
| Max.lifting speed | m/min | 9 | 12 |
| Max.lowering speed | m/min | 7 | 10 |
| Min.turning radius | mm | 1675 | 1250 |
| Steering wheel outer diameter | mm | 180 | 125 |
| Load wheel outer diameter | mm | 180 | 150 |
| Motor power | kw | 1.5 | 1.5 |
| Working voltage | v | 12 | 12 |
| Overall Length | mm | 1600 | 1314 |
| Overall Width | mm | 930 | 760 |
| Overall Height | mm | 1750 | 1900 |
| Max.height | mm | 3440 | 4340 |
| Net.Weight | kg | 480 | 300 |
