Dongfeng 804 Tractor

Dongfeng 804 Tractor thumbnail-1
Dongfeng 804 Tractor photo-1
US$ 3,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Wheel Tractor, 4-cylinder,Upright inline cylinder
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Wheel Tractor, 4-cylinder,Upright inline cylinder
By wheel 4WD
Usage Farm Tractor
Drive Type Other, Gear Drive, 4WD
Power(W) 85hp
Certificate EEC
Brand Name DongFeng
Model Number 804 Tractor
Place of Origin Hubei, China
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Dongfeng 804 Tractor
Good quality with low price;
Best performance ;
Convenient operation ;
High quality

Dongfeng 804 Tractor



Tractor Parameters

Model

DF-804

Drive Type

4WD

Overall Dimensions L*W*H(mm)

4240*2050*2810

Wheel Track(mm)

Front

1610

Rear

1620-2020(1620)

Wheel Base(mm)

2362

Ground Clearance(mm)

Under Front Axle

379

Rated Traction Force(N)

18600/19200

Construction Mass(Kg)

3575

Min. Turning Radius(m)

4.1

Theoretical Speed(km/h)

Forward

2.30,3.60,5.80,8.00,10.0,15.6,25.0,34.9

Reverse

3.10,4.80,7.70,10.80

Engine Specifications

Model

LRC4108T/4MC-T

Type

4-cylinder,Upright inline cylinder radiator cooling,4-storke cycle, direct-injection

Rated Power(Kw/hp)

59.0/80.0,62.5/85.0

Rated Fuel Consumption(g/kw/h)

<242

Rated Speed(rpm)

2300

Bore*Stroke(mm)

108*135/110*135

Total Displacement(L)

4.94/5.13

Drive System

Clutch

Dry Independent type dual Function clutch

Gear Box

4*(2+1)*2

Main Drive

One Pair of Spiral Bevel Gear

Differential

Obturation, four bevel gears

Differential Lock

Mesh gear

Final Transmissions

Planetary reduction gear

Travelling Mechanism

Tyre

front

11.2-24

rear

13.6-38,16.9-34

Steering Gear

Hydraulic steering

Brake

Oil immersed multi-plate disc

Working Device

Hydraulic System

Lifting Capacity at 610 mm Behind Lift Point(Kg)

1600

3-point Suspension

Category: II

P.T.O. Shaft

Rotating Speed(rpm)

540/1000

Spline size

6-φ35 Rectangular spline
