YTO-X804 Wheel Tractor Price

Specifications

YTO-X804 wheel tractor price
High efficiency;
Good after-sales service;
Good performance;
High quality and competitive price

Model	YTO-X804
Tractor
Type	4x4
Overall dimensions (LxWxH) (mm)	4350x2170x2740
Wheelbase (mm)	2314
Min. ground clearance (mm)	430
Min. operating mass (with safety stand) (Kg)	3675
Tyre spec. front / rear	11.2-28 / 13.6-38
Wheel tread, front / rear	1630-1960 / 1500-2100
Steering	Full hydraulic
Brake	Oil immersed, disk type
Diesel engine
Model	LR4B5-23
Type	Four cylinder, vertical, water cooled, four stroke, direct injection combustion
Displacement (L)	4.95
Rated power / speed (Kw) / (r/min)	58.8 / 2300
Max. torque (N.m) / speed (r/min)	270 / 1500-1700
Bore x stroke (mm)	108 x 125
Transmission
Gear shift, forward / backward	12 / 4
Speed range (Km/h), forward / backward	1.63-26.82 / 4.23-12.69
PTO power (Kw)	50
PTO rotation speed (r/min)	540 / 720 or 540 / 1000
Clutch	11-inch, dry, double action
Implement
Three-point linkage category	Three-point linkage category II
Tilling depth control mode	Combined draft, position control and floating control
Lifting force (KN)	16
Options
OECD anti-turnover bar	OECD certified anti-turnover bar or anti-turnover bar with awning
Transmission with shuttle-type gear	12+12
Transmission with creeper gear	24+8
Hydraulic output	2 or 3 group





Our factory:



Other YTO tractor models we can supply:

                 YTO-454 Tractor with Front end loader and backhoe







                                                  YTO-X1004 tractor







If you want to know more information of our other tractor models, please send us Email.
