Chinese Farm Tractor JM284

Chinese Farm Tractor JM284 thumbnail-1
Chinese Farm Tractor JM284 photo-1
US$ 3,000 - 150,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 18.4KW
Certificate EPA
Brand Name Jinma
Model Number JM284
After-sales Service Provided Overseas third-party support available

Specifications

chinese farm tractor JM284
Low emission;EPA/EPC/OECD
Powerful engine;
Good after-sales service:
Good quality with low price;

chinese farm tractor JM284



Technical parameters for chinese farm tractor JM284

Tractor parameters
Model
JM284
Drive type
4WD
Overall dimensions( L*W*H )

3080*1280*1930
Wheel track(mm)
front
1100
rear
1040-1200
Wheel bass(mm)
1645
Ground clearance(mm)
295
Rated traction force(N)
5980
Construction mass(kg)
1140
Min.turning radius(m)
2.8
Engine
Model
3cylinder
Type
3cylinder , water cooled
Rated power(km/hp)
18.4/28
Rated speed(rpm)
2350
Drive system
Clutch
Dual-stage
Gear box
2*(3+1)
Main drive
one pair of spiral bevel gearing
Differential
Bevel gear
Differential lock
Jaw lock
Final transmission
External gearing,spur gear
Traveling mechanism
Type
front
6.00-16
rear
9.5-24
Steering gear
Hydraulic steering
Brake
Disc type
Working device
P.T.O shaft
Rotating speed(rpm)
540/1000
Spline size
6 @ 35 Rectangular spline



Factory for chinese farm tractor JM284



chinese farm tractor JM284chinese farm tractor JM284chinese farm tractor JM284chinese farm tractor JM284
