Jinma 1204 120hp Agricultural Tractor

Jinma 1204 120hp Agricultural Tractor thumbnail-1
Jinma 1204 120hp Agricultural Tractor photo-1
US$ 3,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Hubei Fotma Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Other, Gear Drive, 4WD
Power(W) 88.2kw
Certificate EPA
Brand Name Jinma
Model Number Jinma 1204
After-sales Service Provided Overseas third-party support available

Specifications

Jinma 1204 120hp agricultural tractor
High quality; low price
Easy to operate and maintain
Low noise
Good after-sale service

Jinma 1204 120hp agricultural tractor
       The  Jinma 1204 120hp agricultural tractor is Equipped with wet disc brakes, ensuring desirable braking performance and high reliability. It adopts the planetary end transmission and double action clutches. It is applicable to paddy fields and dry farmlands. It adopts the engagement sleeve gear shifting and force and position combined regulation. It is large in wheel span and axle base, heavy in dead load, and desirable in chassis stability. Besides, it is equipped with safety anti-toppling shelf for optional assemblage.



Details of  Jinma 1204 120hp agricultural tractor in chart



Specification
Tractor parameters
Model
JM1204
Drive type
4WD
Overall dimensions( L*W*H )
4800*2330*2980
Wheel track(mm)
  front
1826-2148
  rear
1680-2268
Wheel bass(mm)
2689
Ground clearance(mm)
475
Rated traction force(N)
26000
Construction mass(kg)
4600
Min.turning radius(m)
6.8
Engine
Model
6cylinder
Type(EPA)
6cylinder engine,
 water cooled
Rated power(km/hp)
88.2(120)
Rated speed(rpm)
2400
Drive system
Clutch
Dual-stage
Gear box
4*(3+1)
Main drive
one pair of spiral bevel gearing
Differential
Bevel gear
Differential lock
Sliding pin, foot operated
Final transmission
Planetary reduction gear
Traveling mechanism
Type
   front
14.9-26
   rear
18.4-38
Steering gear
Hydraulic(power) steering
Brake
Oil
Working device
Hydraulic system
Lifting capacity at 610mm(N)
26000
3-point suspension
Category:2
P.T.O  shaft
Rotating speed(rpm)
540 or 1000
Spline size
6 @ 35 Rectangular spline
Or
21 @ 35 involutes spline











 Related pictures of  Jinma 1204 120hp agricultural tractor





Jinma 1204 120hp agricultural tractor
