Test Bench With Common Rail System Tester

Specifications

With Electronics and Adapting Kits
Test Bench Testing Electronic Pumps and Electronic Fuel Injection Systems
High Quality

Test Bench with Common Rail System Tester

Adopts High Quality Frequency Converter, and Cast Iron Base to Widen and Increase the

Weight of Machine Body. With much more Stability, High Reliability, High Precision, Auto-Protection Function,

Ultra Low Noise.



Technical Parameters:
1. Adjustable Rotation Speed Range: 0~4000 RPM
2. Test Cylinders: 12.
3. Rotation Speed Presetting: 10 kinds.
4. DC. Supply: 12/24V
5. Feeding Pump Motor: 1.1kw
6. Series of Graduate Glass: 45cc, 150cc. The 260cc is Optional
7. Volume of Oil Tank: 60L
8. Main Shafts Center Height: 125mm
9. Flywheel Inertia's Moment: 0.8kg.M2,
10. Stoke Counting: 50-9999
11. Control Temperature of Fuel Oil (°C): 40+2
12. Feed Oil Pressure: Low Pressure 0-0.4MPa, High-Pressure 0-4Mpa.
      Internal Pressure: 0-0.16MPa, 0-1.6MPa.
13. Rotation Direction of Main Shafts: Clockwise or Anticlockwise
14. Packing Dimension: 5M3 CBM
15. Packing Weight: 900kg
16. Output Power: 5.5kw, 7.5kw, 11kw and 15 kw or on Request
17. 3-Phase Power Supply: 380v/50hz or on Request.
18. Color Available: Green, Blue, Red, Yellow or on Customers' Request.





Below Brands are Available:
