Specifications
backhoe loader model: WZ25-20, WZ30-25, WZ30-25 strengthened type, XT870, XT876.
Backhoe loader, also called a loader backhoe, and commonly shortened to backhoe, is an engineering vehicle, which consists of a tractor, fitted with a shovel/bucket on the front and a small backhoe on the back. Due to its (relatively) small size and versatility, backhoe loaders are very common in urban engineering and small construction projects (such as building a small house, fixing city roads etc).
Backhoe loaders are very common and can be used for a wide variety of tasks: construction, small demolitions, light transportation of building materials, powering building equipment, digging holes/excavating, landscaping, breaking asphalt, and paving roads. The backhoe bucket can also be replaced with powered attachments such as a breaker, grapple, auger, or a stump grinder.
Our backhoe loader model is WZ25-20, WZ30-25, WZ30-25 strengthened type, XT870, XT876.
WZ30-25 Main feature:
Adopt the Yuchai engine which is powerful and with low maintenance. It has the high power and good performance ability.
The transmission part adopts the mature component of ZL30 series loader. It has high safety factor.
The leading articulated frame, with the front and axle bridge rationally distributed, makes it has exceptional stability when loading and excavating.
Pneumatic valve control system makes car-stopping brake with urgent brake. So it is safer when braking.
The operation devices are designed according to humanization.
Firstly adopts the pivot control system in the backhoe loader.
The whole day-lighting closed drivers cabin is furnished with the system of the air conditioner, ROPS system. It is safe and comfortable, and the visual field is broad. It adopts the sound insulation, the heat insulation and shock attenuation, which improved the comfortableness of the operating environment.
Various instruments such as four in one bucket, crash hammer can be chosen.
WZ35-35 Mian technical data:
| Description | Unit | XCMG WZ30-25 Backhoe loader |
| Bucket capacity (heaped) | m3 | 1 |
| Rated capacity for bucket | m3 | 0.3 |
| Dumping clearance | mm | 2700 |
| Dumping reach | mm | 950 |
| Max.steering angle | . | 5 |
| Max.steering angle of dig working device | . | 85 |
| Traveling speed I (F/R) | Km/h | 0-6.2 |
| Traveling speed II(F/R) | Km/h | 0-12 |
| Traveling speed III(F/R) | Km/h | 0-20 |
| Traveling speed IV(F/R) | Km/h | 0-33 |
| Back I speed | Km/h | 0-8 |
| Back I I speed | Km/h | 0-28.5 |
| Diesel Model | YC4110 | |
| Engine brand | Chinese Yuchai | |
| Modality | ||
| Rated power | kW | 65 |
| Rated speed | r/min | 2500 |
| Wheel base | mm | 2600 |
| Tread | mm | 1700 |
| Tires | 16/70-24 | |
| Max.digging depth | mm | 4400 |
| Max.digging radium | mm | 5471 |
| Overall dimensions(L*W*H) | mm | 8000*2200*3350 |
| Operating weight | kq | 9500 |
WZ25-20 backhoe loader is a newly developed product of our factory in the latest years. It is the sdc machine which can carry out the operation bothforward and rear position.not only has the loaders funcion but also has the diggingfunction.So its widely used formaterial loading,unloading,transporting and piling,used for ground leveling,and used for underground water pipe,Oil pipe and cable laying.it's kind of wide use,high efficientengineering machinery.Welcome friends both at home and abroad to visit our factory and to order our products.
WZ25-20 Main technical data:
| Rated capacity for bucket | m3 | 0.9 |
| Rated Loading | Kg | 1600 |
| Break out force | KN | 49 |
| Maximum tractive effort | KN | 38 |
| Tipping load | KN | 32 |
| Travel speed in forward 1 | Km/h | 0~11 |
| Travel speed in forward 2 | Km/h | 0~27 |
| Travel speed in reverse 1 | Km/h | 0~10 |
| Travel speed in reverse2 | Km/h | 0~26 |
| Dump height | mm | 2600 |
| Reach fully raised | mm | 880 |
| Hoe bucket capacity | m3 | 0.2~0.3 |
| Maximum digging depth | mm | 4100 |
| Maximum digging radius | mm | 5000 |
| Boom ratation angle | ° | 180 |
| Engine model | 4120BG | |
| 4102GB | ||
| Engine rated power | Kw | 50 |
| Engine rated revolutions per minute | r/min | 2400 |
| Maximum articute angle (Left/Right) | ° | 35 |
| Maximum climbing ability | % | 45 |
| Minimum turning radius (the center of the forward wheel) | mm | 4190 |
| Operating mass | Kg | 6400 |
| Ocerall dimension (L×W×H) | mm | 6500×2060×3300 |
