Specifications
Mini ExcavatorCT18 excavator with 0.05-0.1M3 bucket, LAIYANG,Yanmar engine, CE certificate. steel or rubber track.
CT18 Excavator
Main equipment of standard CT18-7 mini excavator
Laidong diesel engine; 16KW/2200rpm
Originally imported US Parker double-connecting gear pump;
Originally imported Italian Commer waling motor and reducer
Originally imported US Eaton swing motor
Originally imported Italian hydraulic main Valve
Originally imported Italian pilot control lever
Originally imported Italian Oil-sucking valve;
Rubber tracks
Luxury cabin or canopy
Specifications for CT18-7 mini excavator
Power/speed 16KW/2200rpm
Operating weight 1.76t
Bucket capacity 0.04-0.1m3
Bucket digging force 11.44kn
Arm digging force 8.04kn
Pressure of Hydraulic system 16mpa
Hydraulic pump 10+10 (ml/r)
Swing Speed 10.6rpm
Traveling speed 2.25km
Tracking force 11.54kn
Gradeability 30 degree
Ground pressure 23 kpa
Swing angle of arm Left 65/right 52
Undercarriage Width 1050
Center clearance between tracks 850
Undercarriage Width 1080
Length on the ground 1260
Dozer height 242
Dozer width 1100
Dozer lifting height 210
Dozer cutting depth 192
Rear swing radius 1200
Overall length for transportation 3760
Overall height 2250
Clearance under upperstructure 467
Clearance under engine cover 1297
Front swing radius 1612
Track width 230
Max digging height 3149
Max. Digging radius 3680
Max. Digging depth 2091
Max. Dumping height 2076
Max digging radius on the ground 3602
