Paddy Combine Harvesters

Name: Paddy Combine Harvesters
Brand: FOTMA
SKU: 140838342
Availability: InStock

US$ 10,000 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

rice & wheat combine harvester

Type:

Combine Harvester

Hubei Fotma Machinery Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Wuhu port China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application rice & wheat combine harvester

Type Combine Harvester

Drive Type Gear Drive

Usage Other, Rice & Wheat Combine Harvester

Place of Origin Anhui, China

Brand Name FOTMA

Model Number 4LZ-6.0QA

Dimension(L*W*H) 55000x2700x3000mm

Weight 4800kgs

Certificate CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

4LZ-6.0QA Rice & Wheat Combine Harvester

Technical Features

1. Equipped with high-quality engine of 110 horse power, giving a strong driving force;

2. Automatically 270°Hydraulic unloading type to improve working efficiency; Rotary grain tank, easy for maintenance;

3. Equipped with luxury cab with air conditioner;

4. With large cutting width of 2500mm, and 600mm wider paddy field track, better pass ability;

5. Simple operating console, hydraulic chassis driving system.

6. Equipped with double pump and motor, more easy for steering and transmission.

Technical Parameters

Model			4LZ-6.0QA
Feed capacity(kg/s)			6.0
Cabin			Luxurious cab with air conditioning
Weight(kg)			4800
Overall dimension(mm)			5500 x2700x3000mm
Engine	Type		4-cylinder in-line water cooling
	Rated power(kw)		81
	Speed(r/min)		2400
	Fuel		Diesel
	Fuel consumption(kg/hm²)		≤33
Drive system-hydraulic chassis	Track	Specification	90 mm× 60section× 600mm
		Track gauge	1300
	Min. ground clearance(mm)		550
	Transmission		Hydraulic motor
	Number of shifting positions		Stepless speed
	Walking speed(km/h)		0-7.2
Cutting	Reel	Type	Eccentric dial-tooth
		Diameter	900
	Cutting width(mm)		2500
	Blade width(mm)		2500
	Header auger		Spiral blade+Eccentric telescopic rod rack
Grain unloading part	Grain unloading method		270° hydraulic unloading type
	Grain Tank(m³)		1.5(Hydraulic)
