Loader for Sale

Specifications

loader for sale  wheel loader isused in coal mining and other operating environment .its engine ,start,exhaust system and so on all have an explsion-proof function.

.0 Engine Details Date: JAN. 2008

(1) Model Weifang ZH4100K14-3

(2) Engine type: In-line arrangement

(3) Rated Power 45KW(61HP)

Water cooled, four-cycle diesel Engine

(4) Rated Speed 2400 r/min(rpm)

(5) Fuel Consumption ratio in standard

(6) Total displacement 26L working condition 251.6g/kw. H

(7) Lubrication mode pressure splash complex lubrication

2.0 Transmission System

(1) Type Countershaft Power shift

(2) Torque convertor 3-element, single strage

(2) Clutch control oil pressure 1373~1569MPa

(3) Rated input speed 2500 (rpm)

(4) Number of gearshift: Forward ( 2 gearshifts ) Reverse ( 2 gearshifts )

3.0 BUCKET

(1) Bucket Capacity: 0.9 m3

(2) Bucket width: 1910mm

(3) Bucket type: Heavy duty bolt on teeth

(4) Max. Breakout Force: A. Tipper hopper cylinder: 4887, Lifting Cylinder: 2856

(5) Rated Load: 1800kg

(6) Operating Weight: 4800kg

4.0 OVERALL DIMENSION

(1) Overall Length ( Bucket on ground position ): 4952mm

(2) Overall Height

(a) Ground to Cabin Top: 2750mm

(b) Ground to exhaust pipe: It is below from the top of cab

(c) Dumping Height: 2330mm

(3) Overall Width: 1910mm

5.0 OPERATING SPECIFICATIONS

(1) Steering System: Articulated Frame with hydraulic power steering

(2) Min Turning Radius: 4500mm

(3) Driving System: Fluid converter

6.0 Brake System

(1) Service Brake: Hydraulic disc brake on four wheels

(2) Parking Brake: Flexible-shaft external-beam stroke brake

7.0 Wheelbase: 2150mm

8.0 Track: 1440mm

9.0 Tyre type: 16/70 20 Air pressure: Front 0.22Mpa rear: 0.18Mpa
