Home > Products > CPC30 Disel Forklift with CE > forklift truck attachments
forklift truck attachments
- 3000 Set / Sets per Month
- Qingdao China
- T/T
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | SWLTD |
Model Number: | CPC 30 | Type: | Powered Pallet Truck | Power Souce: | Diesel Engine |
Rated Loading Capacity: | 3000 Kg | Max. Lifting Height: | 2720 mm | Min. Lifting Height: | 130 mm |
Fork Length: | 1070 mm | Fork Width: | 130 mm | Overall Dimensions: | 4585*1700*2720(mm) |
Certification: | CE BV | After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
small forklift truck1.High quality
2.Competitive price
3.ISO&CE certificate
4.One year warranty
Features
1. The largesize CPC30 diesel forklift truck is a counter balanced type. It features sound stability and no limitation on service time. The internal combustion forklift truck is used for heavy loads and is often used outside. Its diesel motor has the advantages of better performance (low speed, strong overload ability and strong long-time working ability) and low fuel cost.
2. With its unique appearance, the machine has a streamline effect and the advantages of low noise, vibration reduction, comfort, safety and dustproof. The forklift truck can match with various fork trucks with different hydraulic and mechanical transmission systems according to the needs.
3. Using the full hydraulic steering device theinternal combustion forklifttruck can achieve a small turning radius and features easy steering and safety.
Parameters of CPC30
Classification | Item | Organization | Parameters | ||
Overview | Place of origin | Qingzhou, Shandong Province | |||
Model | CPC30 | ||||
Power form | Diesel fuel | ||||
Rated load | Kg | 3000 | |||
Load center | mm | 500 | |||
Basic dimension | Lifting height | mm | 3000 | ||
Free lift height | mm | 145 | |||
Fork dimension | L x W x T | mm | 1070 X 130 X 45 | ||
Fork spacing (lateral) | Min /Max | mm | 290-1200 | ||
Mast tilt angle | F/R | deg | 6/12 | ||
Front overhang | mm | 480 | |||
External dimension | Total length | mm | 2885 | ||
Total width | mm | 1230 | |||
Mast lowered height | mm | 2182 | |||
Mast raised height | mm | 4040 | |||
Overhead guard height | mm | 2160 | |||
Min turning radius | mm | 2540 | |||
Min width of intersecting aisle | mm | 2490 | |||
Min width of right-angle stacking channel | mm | 3020+F+J | |||
Property | Velocity | Travel speed (empty load) | Km/h | 21 | |
Lifting speed (full load) | mm/s | 490 | |||
Max climbing ability | % | 20 | |||
Dead weight | Kg | 4300 | |||
Tire | Radial Tire | Front wheel | 8.25-12-12PR | ||
Real wheel | 6.50-10-10PR | ||||
Wheel tread | Front wheel | mm | 1030 | ||
Real wheel | mm | 974 | |||
Wheel base | mm | 1760 | |||
Min ground clearance | mm | 120 | |||
Power and transmission | Storage battery | Voltage | V/Ah | 12/105 | |
Engine | Model | 490BPG-53 | |||
Place of origin | Xinchai Power, Zhejiang Province | ||||
Output power | Kw/r.p.m | 37/2650 | |||
Rated torque | N.m/r.p.m | 148/1900 | |||
Number of cylinders | 4 | ||||
Cylinder bore X travel | mm | 90 X 100 | |||
Displacement | cc | 2540 | |||
Oil tank capacity | L | 65 | |||
Min fuel consumption rate | g/Kw.h | 238 | |||
Transmission | Place of origin | Zhongnan Transmission, Changsha City | |||
Gear (front and rear) | 3/2 | ||||
Operating pressure | Mpa | 16 |
Product Characteristics
· Integrated central control box the reliability of electric system
· Ergonomical design ensures best operation
· Energy-saving hydraulic system decreases fuel consumption
· High-quality hydraulic hoses, no oil leakage
· Wide-view mast design improves the productivity and safety
1 Digital intelligent drivemonitoring system can facilitate obtaining an operating data of forklifts so as to achieve the whole-process control.
2 Full hydraulic steering system reduces the operator’s fatigue greatly; it uses a horizontal oil cylinder on the compact steering axle, and garantees a steering reliability.
3 The classically YTO ASF space frame structure applies an ergonomic & aesthetic design with an elegant outlook, a compact structure, and a comfortability in operation.
4 The optimized rail section design of the mast has the driver enjoyed a wide-view.
