Forklift Price With ce CPC30

category

 Item

Unit

specification

general situation

Habitat

Qingzhou shandong

 Model

CPC30

 power form

diesel

Rate Load

Kg

3000

Load Center

mm

500

basic size

lifting altitude

mm

3000

lifting freely altitude

mm

145

fork size

L x W x T

mm

1070 X 130 X 45

distance between the forks

Min ·/Max

mm

290-1200

mast tilt angle

F/R

deg

6/12

Front overhang

mm

480

Size

 length

mm

2885

 width

mm

1230

height when portal not lift

mm

2182

height when portal lift

mm

4040

reliefbracket height

mm

2160

min.tuming radius

mm

2540

min right angle aisle width

mm

2490

Minimum stacking right Angle channel width

mm

3020+F+J

performance

speed

drive speed (no-load)

Km/h

21

drive speed (load)

mm/s

490

max. climbing power

%

20

 weight

Kg

4300

tire

tire

front wheel

8.25-12-12PR

rear wheel

6.50-10-10PR

wheelspan

front wheel

mm

1030

rear wheel

mm

974

axle distance

mm

1760

Minimum Ground Clearance

mm

120

Power and transmission

accumulator

pressure

V/Ah

12/105

Engine

model

490BPG-53

habitat

Xinchai

output power

Kw/r·p·m

37/2650

rated torque

N·m/r·p·m

148/1900

no. of cylinder

4

cylinder x schedule

mm

90 X 100

air displacement

cc

2540

fuel-tank capacity

L

65

minimum specific fuel consumption

g/kw·h

238

transmission

habitat

Chasha zhongnan

gears(front/after)

3/2

working pressure

Mpa

16
