2014 CPC30 Forklift Truck

Name: 2014 CPC30 Forklift Truck
Brand: SWLTD
SKU: 140827884
Availability: InStock

US$ 8,100 - 9,100 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

SWLTD

Shandong Weili World Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name SWLTD

Model Number CPC30

Type Manual Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 3000KG

Max. Lifting Height 3000mm-7300mm

Min. Lifting Height 3000mm

Fork Length 1070mm

Fork Width 125mm

Overall Dimensions 3605*1160*2095

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

MODEL		CPC30
Load capacity		3000 kg
Load center		500 mm
Power type		Diesel
Max. lifting speeds(with load)		400 mm/s
Max. driving speeds(with/without load)		18/20 km/h
Max towering (with load)		15.5/10.5 kn
Grade ability(with load)		15/20 %
Lifting height		3000 mm
Free lift		80 mm
Tilting angles(forward-backward)		6°/12°
Min. turning radius		2500 mm
Min. Right angle aisle width		2110 mm
Min. under-clearance		135 mm
Dimensions	Overall length(including fork)	3800 mm
	Overall width	1230 mm
	Overall height(mast lowered)	2110 mm
	Overall height(mast extended)	4270 mm
Overall height to overhead guard		2110 mm
Fork overhang		465 mm
Wheel base		1700 mm
Tread	Front tread	1000 mm
	Rear tread	970 mm
Tire	Front tire	28×9-15
	Rear tire	6.50-10
Total weight		4320 kg
Fork width		125 mm
Fork thickness		45 mm
Backrest height		1225 mm
Fork length		1220 mm
Engine	Engine model	490
	Rated power	39 kw
	Rotate speed at rated power	2650 rpm
	Max. Torque	157 nm
	Rotate speed at max. Torque	1980 rpm
Type of power shift		Tor-con
