small diesel engine 9.5HP
- 6000 Set / Sets per Month
- CHONGQING
- T/T
You May Like
Product Details
| Usage | Other, Agriculture | Fuel | Diesel | |
| Stroke | 4 Stroke | Cylinder | Single Cylinder | |
| Cold Style | Other, Water-cooled | Start | Electric Start | |
| Place of Origin | Chongqing, China | Brand Name | GOLDEN BOW | |
| Model Number | G95A |
Product Description
Technical Specification
NO. | ITEMS | UNIT | MODEL |
G95A | |||
1 | Type |
| Single cylinder, horizontal, water-cooled, 4-cycle |
2 | Bore×stroke | mm×mm | 86×90 |
3 | Displacement | mL | 522 |
4 | Rated speed | r/min | 2400 |
5 | Continuous rated output | Hp | 8.5 |
6 | Max. output | Hp | 9.5 |
7 | Idle speed | r/min | ≤600 |
8 | Compression ratio |
| 21.5:1 |
9 | Cooling system |
| Radiator |
10 | Combustion system |
| (TVCS) Three vortex combustion system |
11 | Fuel delivery position |
| 20°~22° |
12 | Fuel injection pressure | kgf/cm2 | 125~130 |
13 | Lubricating system |
| Forced lubrication with trochoid pump |
14 | Starting system |
| Electric startup,Speed doubling handle hand |
15 | Direction of rotation |
| Counter clockwise facing flywheel |
16 | Cooling water capacity | L | 2.1(Radiator) |
17 | Fuel tank capacity | L | 10 |
18 | Crankcase oil capacity | L | 2.3 |
19 | Measurement | mm | 765×350×520 |
20 | Net weight | kg | 110 |
