DongFeng One With Two Wrecker Truck

DongFeng One With Two Wrecker Truck photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Fuel Type:
Diesel
Emission Standard:
Euro 2
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai
Delivery Detail:
Delivery time depends on order quantity.
Fuel Type Diesel
Emission Standard Euro 2
Condition New
Transmission Type Manual
Dimensions (L x W x H) (mm) 7310*2300*2370
Place of Origin Hubei, China
Brand Name CLW
Model Number CLW5070TQZ

Specifications

wrecker truck
Dongfeng 4*2 wrecker truck
Lift Weight: 2000kg
Engine: CY4102BZLQ
Horsepower: 180hp

Item

Unit

Parameter

Model



CLW5070TQZ wrecker truck

Chassis



EQ1061TJ

Overall dimension

mm

7310×2300×2370

Fact lift weight

kg

1800-2000

Mass in working order

5200

Arm extension stroke of lift

mm

630

Max loading weight

kg

6000

Max starting force

KN

29.4

Case dimension

mm

/

Wheel base

3800 mm

Engine type

CY4102BZLQ

F/R track base

1750/1586mm

Exhaust/hp

3856/120 ml/ps

F/R over hang

1110/1260mm

fuel consumption / 100 km

13L

Approach/Departure angle

18/14 °

Min turning radius

12 m

Max speed

90 km/h

Max grade ability

25°

Tire

7.00-16,7.50-16

Min ground clearance

176 mm

Armor plate spring quantity

7/8+5

Gearbox

5 speeds

Brake System

Exhaust brake

Clutch

242 mm

Brake space

8m

Air condition

optional

Traction system

4×2

Electric system

12v

Number of axles

2

Allowable passengers in cab

2

Function brief introduction

Main features are: Equipped with hydraulic pressure system, neat-structured, flexible and reliable.

The crane, which functions with single vat, can be landed to support the truck and guarantee the truck’s stability. It can be equipped with either semi-automatic or fully automatic tugboat.

The capstan can be driven either by hydraulic pressure or power supply of the truck itself. Accessories for clearing the barriers are sound-equipped to secure the efficient work. The traction supporting crane operated by the hydraulic pressure system is highly flexible.

The assistant wheel can hold the locked wheels to tract.

It is also equipped with high-latitude signal lamp. Searching lamps can also be equipped to guarantee night barrier-cleaning work.

Tools operated by high pressure for dismantling barriers can be equipped to do saving activities on spot.

DongFeng one with two wrecker truckDongFeng one with two wrecker truckDongFeng one with two wrecker truck

DongFeng one with two wrecker truck
