Dongfeng 4x2 Water Pump Truck,off-road Water Truck,water Well Pump Trucks

Chengli Special Automobile Co., Ltd.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Storage:

Oil

Drive Wheel:

4x2

Payment & Shipping

Payment Methods:

Port of Shipment:

Shang Hai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Storage Oil

Drive Wheel 4x2

Horsepower 150 - 250hp

Transmission Type Manual

Fuel Type Diesel

Tank Volume 5001 - 10000L

Engine Capacity 3856/88 ml/kw

Dimensions (L x W x H) (mm) 6950*2095*2350

Brand Name CLW

Place of Origin Hubei, China

Model Number SNJ5070GYY

Gross Vehicle Weight 5100

Specifications

dongfeng 4x2 water pump truck
The stuff of tank is 5mm thick of Carbon Steel, and the tank can be divided into several sparate

dongfeng 4x2 water pump truck

Item		unit	parameter
Vehicle model			SNJ5070GYY Fuel Tanker
Chassis model			EQ1071GJ3
Overall dimensions		mm	6950×2095×2350
	Fact cubage	L	4500-5000
	GVW	kg	Appro×7000
	Rated loading capacity		Appro×2800
	Mass in working order		Appro×4005
	Body internal dimensions	mm	4280×1490×860
	Wheel base		3800
	F/R track base		1750/1586
	Approach/departure angle	°	18/14
Exhaust/hp		ml/kw	3856/88
Max speed		km/h	90
Tire specification		7.50-16 12PR	Engine type	CY4102BZLQ
Traction system		4×2	transmission	5-speed with over drive
Number of axles		2	Electric system	24v
Operation control system		Electrically hydraulic control	Allowable passengers in cab	3
Equipment		Meterial:5mm carbon steel.can choose flow meter, tankerpiston and bobbin disk Tank can be separated to several unattached small tanks to fill different fuels
Engine		Chaoyang diesel engine
Production cycle		7-10days
