Dongfeng 2T lhd mini crane truck

Specifications

Dongfeng 2T lhd mini crane truck
1>Max lifting capacity: 2T
2>Max loading capacity: 5T
3>Engine power: 102hp

Dongfeng 2T lhd mini crane truck

Item		Unit	Parameter
Product		/	Crane truck
Gross weight		kg	5495
Curb weight			3470
Overall dimensions		mm	5995×2000×2900
Front/rear suspension			1032/1663
Wheelbase			3300
Tread	Front		1404
	Rear		1458
Leaf spring number		/	8/9+5
Axle number		/	2
Axle-load		kg	2500/2995
Tire specification		7.00R16
Engine	Model	/	YCND27-100-30
	Displacement	ml	2659
	Power	kw/hps	75/102
Other Main Parameters		Cargo box	Max loading capacity(T) 5
			Dimension(mm): 2850×1800×400
		Crane	Crane Brand: XCMG
			Crane Model: SQ2
			Max lifting capacity(T): 2
			Max lifting height(m): 6.5
			Working radius(m): 5.2
			Turning angle: 360°
			Arm Nos.: 2

Payment terms and delivery:

Delivery date: 7-10 days

Payment terms: 30% TT as deposit and 70% TT upon receipt of B/L copy

Packing: nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements

Remarks:

The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.

Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:

Reference Picture:
