Dongfeng 4*2 Vacuum Sewage Suction Truck

Chengli Special Automobile Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Transmission Type:

Manual

Condition:

New

Emission Standard:

Euro 3

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Transmission Type Manual

Condition New

Emission Standard Euro 3

Fuel Type Diesel

Tank Volume 2500L

Dimension (L x W x H) 5995*2000*2550mm

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5060GXW3

Horsepower 90hp

Gross Vehicle Weight 6495

Dongfeng 4*2 vacuum sewage suction truck

Specifications:

Product	Sewage Suction Truck
Vehicle model	CLW5060GXW3
Chassis model	EQ1060TJ20D3
Gross weight	6495
Chassis parameters	Overall dimensions	mm			5995×2000×2550
	Tank dimensions				3000×1050
	Kerb weight	kg			4385
	Rated payload				1980,1915
	Approach/Departure angle	°			19/14
	Suspension F/R	mm			1032/1663
	Wheel base				3300
	F/R tread				1506/1466
	Drive type				4*2
	Number of axles				2
	Axle-load	Kg			2805/3690
	Number of Spring leafs				8/9+5,6/8+4
	Clutch				uniwafer ,dry clutch, hydraulic remote control
	Braking system				Air braking
	Steering gear				recirculating ball type steering wheel
	Tire specification				7.00-16,6.50-16,7.00R16,6.50R16
	Number of Tires				6
	Electric system				24v
	Allowable passengers in cab				2,3
	Air-condition				Optional
Engine	Engine model				YC4F90-30
	Type of fuel				Diesel
	Displacement			ml	2659
	Hp/Power				90/66
	Operation control system				Power Steering
	transmission				6-speed with over drive
	Max speed		Km/h		90
	Manufacturer				Guangxi Yuchai Co., Ltd
	Emission standard(TAS)				EURO 3
Special performance & Equipment	1, Equipped with vacuum pump(rating rotate speed=1400r/m, min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, clockwise) 2, Equipped with power take off, transmission shaft, fecal tank, pipe network, fecal pipe for observing and cleanout equipment 3, Time for full suction<5min
Production cycle	7-10
