Dongfeng TIANJIN Fire Truck,fire Fighting Vehicle

Name

Dongfeng TIANJIN

fire truck

L×W×H mm

 8120×2480×3350 (mm)

Chassis Model

DFL1160BX2

Total mass

15000 (Kg)

Rated mass

6000 (Kg)

Curb mass

8550 (Kg)

Approach/Departure angle

20/13 (°)

Front/rear suspension

1430/2130 (mm)

Engine

ISDe210 30

Manufacture

Dongfeng Cummins Engine Co., Ltd.

Power(kw)

155

Displacement(ml)

6700

Emission standards

GB3847-2005,GB17691-2005

Max. speed

90

Axle

2

Wheelbase

4500,4200

Front tread

 1880(mm)

Rear tread

1800(mm)

Tyre

6

Tyre size

10.00R20

Fuel type

diesel

Spring

        8/10+8

Axle load

5270/9730

 Cab passenger

2+4

Note

The watering truck loading for 6000kg; tank volume: 6 cubic meters; tank size ( length * width * height ): 3760 x 1250 x 1280 ( mm );
